Matrix Telecom SARVAM UMG Quick Start Manual page 19

Configuration of the S/T interface (RJ-45) on NT1
Pin Number Pin Details
3
4
5
6
Pin details of BRI Port in TE mode
Pin Number Signal
1
2
3
4
5
6
7 VOUT-
8 VOUT+
Pin details of BRI Port in NT Mode
Pin Number Signal
1
2
3
4
5
6
7 VOUT-
8 VOUT+
Matrix SARVAM UMG Quick Start
Rx1
Tx1
Tx2
Rx2
Color
-- Orange-White
-- Orange
TX-A Green-White
RX_A Blue
RX_B Blue-White
TX_B Green
Brown-White
Brown
Color
-- Orange-White
-- Orange
RX-A Green-White
TX_A Blue
TX_B Blue-White
RX_B Green
Brown-White
Brown
