• A standalone PC or a PC connected in LAN.
• A SIM card to test mobile network connectivity.
• A SIP Account to test VoIP connectivity.
• Make sure you have separate electrical earth and telecom earth for the safety of the product
and the people handling it.
• Always wear a properly earthed (grounded) electrostatic discharge preventive belt or wrist strap
while handling the cards of the System.
• Use Primary Protection on trunk and long distance extension lines to protect the system from
lightning and electrical surges.
• Do not install the system near any source of water, corrosive fumes, and electromagnetic noise
such as radio equipment, heavy transformers, faulty electric chokes of tube-lights, device
having a faulty coil, to avoid electromagnetic effect.
For detailed instructions, refer to the System Manual.
• Unpack the system.
• Make sure that your package contains all the below items. If any item is missing or damaged,
please contact the source from where you have purchased the system.
• ETERNITY GENX
• Two cables with RJ45 connectors on both ends
• 3-pin Power Cord, MC-4 Black
• 3-pin DC Input Cable
• Two Screws M 7/30 for Wall Mounting
• Two Screw Grips for Wall Mounting
• Two Side Clamps
• Four Screw M4X12 CSK for the Side Clamp
• Mounting Templates
1. ETERNITY GENX AC with factory fitted AC Power Supply and CPU cards.
ETERNITY GENX DC with factory fitted DC Power Supply and CPU cards.
2. Supplied with ETERNITY GENX AC.
3. Supplied with ETERNITY GENX DC.
• Place the system at the location you have selected.
• To install the ETERNITY GENX Cards,
