Matrix Telecom SARVAM UMG Quick Start Manual page 49

ETERNITY GE SLT16
1
2
3
4
45
Connector Color
RJ45-1 Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
RJ45-2 Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
RJ45-3 Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
RJ45-4 Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Connection H/w Port Offset
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
SLT
Matrix SARVAM UMG Quick Start
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
