LED indication for Mobile Ports
Event
Port Idle
Port Active (All states other than
Ring and Speech)
Ring Event
Speech
Module Initialization
PUK required
SIM PIN faulty
SIM Absent
Network Link Down (absence of
GSM Network)
20
Cadence in msec
LED Color
(1 cadence is of 3000msec)
--
LED Off
Red
Continuous On
Green
400ms On-200 ms Off-
400ms On-200 ms Off
Green
Continuous On
Orange
200ms On-200ms Off-
200ms On-200ms Off-
200ms On-200ms Off-
200msOn-200ms Off-
200ms On-1200ms Off (5 Blinks)
Orange
200ms On-200ms Off-
200ms On-200ms Off-
200ms On-200ms Off-
200msOn-1600ms Off
Orange
200ms On-200ms Off-
200ms On-200ms Off-
200ms On-2000ms Off (3 Blinks)
Orange
200ms On-200ms Off-
200ms On- 2400ms Off (2 Blinks)
Orange
200 ms On-2800 ms Off (1 Blink)
