Title page
Nortel Networks Communication Server 1000
Nortel Networks Communication Server 1000 Release 4.0
WLAN IP Telephony
Installation and Configuration
Document Number: 553-3001-304
Document Release: Standard 3.00
Date: September 2004
Year Publish FCC TM
Copyright © 2004 Nortel Networks
All Rights Reserved
Produced in Canada
Information is subject to change without notice. Nortel Networks reserves the right to make changes in design
or components as progress in engineering and manufacturing may warrant.
SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.
