6. GRAPHICAL INTERFACE
The graphical interface of the M1/M3 has been designed to be easy to use and
intuitive. This section gives you a preview of the different screens and commands
available
6.1.
2 MAIN PARTS
The graphical interface of your M3 is divided in 2 main parts:
1. A part that allows configuring the device and the measure. It consists of an
icon desktop with windows.
Icon desktop
The second part (measuring screen) can be reached by pressing the
2. This part allows to see the measurement result and to use them. The M3
starts on this screen. For reaching the configuration screens, press on the
button
Page 26
Icon desktop with configuration windows
button
Example of measuring screen
M1 – M3 Display units
Press on this
icon to reach
the main icon
desktop for
configuring
your device
