8.3.
Temporary dynamic mode
As explained on the chapter 5.1, the characteristic is defined either as « static »
(direct) or « dynamic » (Max, Min ...)
If a characteristic has been adjusted as static, it is nevertheless possible to change
temporarily to a dynamic mode, directly from the measuring screen.
To change the measuring mode, press on the icon as shown on the above picture.
Static
Max
Min
Max-Min
Average
Median
When a dynamic mode has been selected, press on the
footswitch (if configured as « init dyn » (see chap 7.4)) to start recording.
Page 64
(only adapted on an automatic fixture)
The displayed value is calculated with the formula (MAX-MIN)/2.
M1 – M3 Display units
button or on the
