M1 – M3 Display units
7.1.4. Part 3 control limit
This screen allows to display or not the control limits (warnings) and to define them.
Control limits are warning that informs the user is the measure becomes too close to
the tolerances limits. (Yellow colour on the bargraph)
This part is hidden if « no » has been selected
Example of characteristic displayed with control limits
Part OK
Part OK with warning
Part Not OK
Page 39
