45173
RS232/USB cable converter :
This cable allows a M1/M3 display to
communicate with a computer. It creates a virtual
COM port on the computer. It is delivered with a
driver on a CD.
ACS-
Tickets printer
Allows to print the displayed value of the M1/M3
AFF-
002
Requires cable ref 45179 to be connected to the
+
M1 / M3
45179
QR code reader for Metro displays.
ACS-
AFF-
2 main functions :
003
- Allow to send a configuration on the display
(part definition, tolerance, display type,
calibration of the air gage, etc...)
- Send a Manufacturing order number. The
export file will take the name of the number
entered.
ACS-
Air cut-off footswitch
Allows to simply cut off the air supply, for
PNE-
stopping the air flow when the air gage is not
012
used.
Page 14
M1 – M3 Display units
