3. INTRODUCTION
3.1.
PRODUCT PRESENTATION
The M1 and M3 display units allow making dimensional control using 1 or 2 air gages.
Depending on the version it is possible to make simple measurement (with one air
gage), or display 2 characteristics on the screen and can make static measurement or
dynamic (Max, Min, Max-Min...)
The M1-M3 can be connected to a PC thanks to its RS232 or USB connection.
A footswitch can be connected in order to transfer measurements.
The M1 / M3 displays for air gages requires 2 (eventually 3) masters for calibration.
3.2. VERSIONS
REF
11040
13040
Page 6
M1 – M3 Display units
Description
Display unit M1 for 1 air gage
Display unit M3 for 2 air gages or 1 air
gage with 2 measuring levels
