M3
The manufacturer is not responsible for mistakes that could be found in this handbook
and also for direct or indirect damage resulting from the equipment, its performances
and the use of this product.
It is the responsibility of the user to verify the calibration of the display before
measuring and it is advised to check periodically the calibration and
measurement performance.
CLEANING
Use a soft cotton cloth slightly soaked with an ethyl alcohol based product.
DO NOT USE the following products: acetone, benzene, toluene and halogens
hydrocarbons.

3. INTRODUCTION

3.1.

PRODUCT PRESENTATION

The M3 display unit allows making dimensional control using 1 or 2 probes.
It is possible to make simple measurement (with one probe), or combined
measurement (with 2 probes): sums or differences. It is possible to display 1 or 2
characteristics on the screen and can make static measurement or dynamic (Max,
Min, Max-Min...)
The M3 can be connected to a PC thanks to its RS232 or USB connection.
A footswitch can be connected in order to transfer measurements.

3.2. VERSIONS

The following probes can be connected
M3 Reference
13000
13010
13020
Description
2 x TTL probe or encoder : Direct
connection of Heidenhain and through
and adaptor for Magnescale (DK series)
and Mitutoyo (LG series)
2 x inductive probes from Metro
2 x incremental probes or encoder from
