Connector Name: CAM (Camera Connection Interface)
A face
Definition
A1
GND
A2
NC
A3
NC
A4
VCC
A5
RXD
A6
NC
A7
NC
A8
TXD
A9
VCC
A10
NC
A11
NC
A12
GND
Type specification
Type-C
Connector
Type
Type-C
Adapted
connector
Plug
Connector name: EXT (third party GPS connection interface)
Node
Signal
1
5VDC
2
GPS_TX
3
GPS_RX
4
NC
5
NC
6
GND
Type specifications
SM06B-GHS-TB
Connector Type
GHR-6V-S Recommendation AWG28 Wire
Fit connector plug
MS600V2 Universal Multi-Spectral
Camera User's Manual
B face
Definition
B1
GND
B2
NC
B3
NC
B4
VCC
B5
RXD
B6
NC
B7
NC
B8
TXD
B9
VCC
B10
NC
B11
NC
B12
GND
Description
Output to GPS power supply ,≤500 mA
3.3 V UART
3.3 V UART
NC
NC
Signal/power ground
29
Description
Signal/power ground
DLS supply ,5 V
3.3 V Level UART
3.3 V Level UART
DLS power supply ,5 V
Signal/power ground
