Foxtech SurePulse VS User Manual page 39

Connector Name: External Connector
Node Definition
PIN1 GND
PIN2 NET_TRXN3
PIN3 NET_TRXP3
PIN4 NET_TRXN2
PIN5 NET_TRXP2
PIN6 NET_TRXN1
PIN7 NET_TRXP1
PIN8 NET_TRXN0
PIN9 NET_TRXP0
PIN10 GND
PIN11 GND
PIN12 5V
PIN13 5V
PIN14 UART2_RXD
PIN15 UART2_TXD
PIN16 UART1_RXD
PIN17 UART1_TXD
PIN18 GND
PIN19 NC
PIN20 NC
PIN21 PWM_IN
PIN22 PWM_OUT
PIN23 GND
PIN24 PWR_GND
PIN25 PWR_GND
PIN26 PWR_GND
PIN27 PWR_GND
PIN28 PWR_IN
PIN29 PWR_IN
PIN30 PWR_IN
PIN31 PWR_IN
Type specifications
Connector Type
MS600V2 Universal Multi-Spectral
Camera User's Manual
Note Description
Signal ground
Brown (not connected)
Brown white (not connected)
Blue
Blue and white (not connected)
Net port
Green
Green white
Orange
Orange white
Signal ground
Signal ground
DLS External Power Maximum current ≤500 mA
supply
DLS
API serial port TTL
Signal ground
Reservations
Standard voltage: 3.3 VDC;
Input voltage range :0.0 VDC-5.0VDC;
PWM signal frequency range :50 Hz-400Hz
PWM
Standard voltage: 3.3VDC;
Input voltage range: 0.0VDC-5.0VDC;
Signal ground
External power
Camera input voltage 7VDC-30VDC ;
supply
average 6W, peak 9W (excluding
(black)
external DLS Module)
Mean 7W, peak 10W (including external
External power
DLS Module
supply
(red)
SHLVP-31V-S-1
27
(not connected)
