Fit connector plug
If the GND of trigger signal is different from the power supply GND, must not
to connect GND only at the camera.
6.2.2 D LS interface
The MS600V2 DLS has two external connector interfaces: camera
connection, third party GPS connection interface; DLS with built-in
GPS module, by default do not need to connect to third-party GPS
module.
When a third-party GPS module is used, the GPS module that meets the
NMEA-0183 protocol needs to be plugged in EXT interface, the DLS
will automatically switch to use the third-party GPS module;
recommended to use UBLOX M8N GPS module Pixhack version.
MS600V2 Universal Multi-Spectral
Camera User's Manual
SM31B-SHLVS-G-TB Recommendation AWG28 Wire
Attention
28
