The steps of the upgrade process are as follow:
1 ) Ensure that the DLS is properly connected with the camera;
2 ) Copy the upgrade package file (. bin format) to the card root
directory;
3 ) Power off the camera, insert memory card;
4 ) Power-on Camera,start automatic upgrade;
5 ) During the upgrade process, the camera status light flashes blue;
6 ) After the upgrade is successful, the camera status light
becomes green; if the upgrade fails, the status light becomes red,
repeat step 4) until the upgrade is successful, if you can not
upgrade successfully many times, please contact us for technical
support;
7 ) After the upgrade is complete, restart the camera and view the
firmware version number on the WEB page to confirm that the
upgrade is successful.
It is strictly prohibited to put 2 or more different versions of the
upgrade package in the same memory card;
After the firmware upgrade, when re-using the mobile terminal WEB page to
configure the device, it is recommended to clear the browser cache.

6. Installation and interface definition

6.1 Mechanical interface
There are 4 M3 screw holes at the bottom of the MS600V2 main frame
for installation.
Ensure that all surfaces of the camera have air convection, which is very
necessary for heat dissipation.The camera's mounting surface should not
completely covered or isolated when installed on the UAV.
MS600V2 Universal Multi-Spectral
Camera User's Manual
Attention
Attention
25
