3.3.3 The relationship between the course overlap and the speed-to-height
ratio of the aircraft
The minimum shooting interval of MS600 V2 multispectral camera is 1 second, the
shooting interval is less than this value, the phenomenon of missed shooting will
occur. In order to avoid this situation, we can refer to the following table.
Flight heading
altitude overlap
(m) (%)
40 80
80 80
120 80
160 80
200 80
300 80
500 80
The speed in the above table refers to the speed relative to the ground, and
the flight altitude refers to the altitude of the UAV, generally relative to the
altitude of the take-off point.

3.3.4 External Trigger Mode

1) Before the external trigger mode is used, ensure that the
effective trigger signal is properly connected to the camera;
2) Select "external trigger " in Auto capture mode drop-down menu;
3) The drop-down menu includes three trigger settings, as follow:
Settings
Note
Rising edge
The camera is photographed according to the rising edge of
the pulse
Falling edge
The camera is photographed according to the falling edge of
the pulse
PWM
The camera will trigger when it switches from less than the
threshold to greater than the threshold.
MS600V2 Universal Multi-Spectral
Camera User's Manual
Maximum speed
(m/s)
70 3.2 4.8
70 6.4 9.6
70 9.6 14.4
70 12.8 19.2
70 16 24
70 24 36
70 40 60
Attention
10
Ground resolution view angle
(cm/pixel)
2.88
5.77
8.65
11.54
14.42
21.63
36.06
(㎡)
37×28
74×55
110×83
148×111
185×138
277×208
426×346
