COMMUNICATION

Provision for communication and supervision is
integrated as standard into the COMPACT. The unit
is ready to be connected via EIA-485 and Ethernet.
For particulars of connecting and wiring the air
handling unit, see Section 20.3.3 Wiring to Termi-
nals.
Communication can also be established via Ether-
net without software other than an ordinary web
browser such as Internet Explorer.
Further information about interfaces, proto-
col and configuration is available at www.
swegon.se (com) under Products/Air handling
units/COMPACT air handling units/Documen-
tation.
15.1 EIA-485
Protocol and settings for EIA-485 is specified.
Settings:
Value
Modbus RTU
Metasys N2
Lon Works
Exolinc

15.2 Ethernet

Protocol and settings for Ethernet is specified.
Settings:
Value
Ethernet
16

SERVICE LEVEL

A code and special training are required for access to this
menu group.
Registered design. The company reserves the right to make design changes without prior notice.
Setting range
Address, speed, parity, stop bits
Setting range
MAC ID
DHCP SERVER
(active or inactive)
IP ADDRESS
(static or dynamic + port no.)
SUBNETM.
GATEWAY
DNS-SERVER
MODBUS TCP CLIENT
(IP address, netmask and port
number)
BACNet IP
(active or inactive, Device ID,
Port no.)
INSTALLATION
COMMUNICATION
INSTALLATION
SERVICE LEV.
GB.COMPACTAHSK.210520
*COMMUNICATION*
EIA-485
ETHERNET
*SERVICE LEV.*
CODE:0000
