COMMUNICATION

Provision for communication and supervision is
integrated as standard into the COMPACT. The unit
is ready to be connected via EIA-485 and Ethernet.
For particulars of connecting and wiring the air
handling unit, see Section 21.3.3 Wiring to Termi-
nals.
Communication can also be established via Ether-
net without software other than an ordinary web
browser such as Internet Explorer.
Further information about interfaces, proto-
col and confi guration is available at www.
swegon.se (com) under Products/Air handling
units/COMPACT air handling units/Documen-
tation.
16.1 EIA-485
Protocol and settings for EIA-485 is specifi ed.
Settings:
Value
Modbus RTU
Metasys N2
Lon Works
Exolinc

16.2 Ethernet

Protocol and settings for Ethernet is specifi ed.
Settings:
Value
Ethernet
17

SERVICE LEVEL

A code and special training are required for access to this
menu group.
44 www.swegon.com
Setting range
Address, speed, parity, stop bits
Setting range
MAC ID
DHCP SERVER
(active or inactive)
IP ADDRESS
(static or dynamic + port no.)
SUBNETM.
GATEWAY
DNS-SERVER
MODBUS TCP CLIENT
(IP address and mesh +
port no.)
Registered design. The company reserves the right to make design changes without prior notice.
INSTALLATION
COMMUNICATION
INSTALLATION
SERVICE LEV.
GB.COMPACTAH.101110
*COMMUNICATION*
EIA-485
ETHERNET
*SERVICE LEV.*
CODE:0000
