Function
1
External fire alarm tripped
2
Internal fire alarm tripped
4
R.HX. speed monitor tripped
6
Supply air temp sensor defective
7
Extract air temp sensor defective
8
Outdoor air temp sensor defective
9
No communication to r.hx. controller
10
No communication to SA frequency conv.
11
No communication to EA frequency conv.
12
Over current in SA frequency conv.
13
Over current in EA frequency conv.
14
Under voltage in SA frequency conv.
15
Under voltage in EA frequency conv.
18
Over temperature in SA frequency conv.
19
Over temperature in EA frequency conv.
20
No communication SA frequency range
gateway
21
No communication EA frequency range
gateway
22
Hall sensor defective SA frequency range
23
Hall sensor defective EA frequency range
24
SA frequency range blocked
25
EA frequency range blocked
26
Start-up failure SA frequency range
27
Over voltage in EA-2 frequency conv.
30
Ext. EA/room temp sensor defective
31
Ext. outdoor temp sensor defective
34
Over current in r.hx. controller
35
Under voltage in r.hx. controller
36
Over voltage in r.hx. controller
37
Over temperature in r.hx. controller
38
R.hx pressure drop above alarm limit
39
El.heating coil tripped
40
Extract air temp below alarm limit
41
Supply air temp below setpoint
42
Ext.alarm No.1 tripped
43
Ext. alarm No.2 tripped
48
Supply airflow below setpoint
49
Extract airflow below setpoint
50
Supply airflow above setpoint
51
Extract airflow above setpoint
52
Supply air filter dirty
53
Extract air filter dirty
54
Service period past alarm limit
55
No comm. SA air flow pressure sensor
56
No comm. EA air flow pressure sensor
Registered design. The company reserves the right to make design changes without prior notice.
Factory preset value
Priority
Indication
LED
0=blocked
A=A alarm
0=Off
B=B alarm
1=On
A****
1
A****
1
A
1
A
1
A
1
B
1
A ***
1
A ***
1
A ***
1
A ***
1
A ***
1
A ***
1
A ***
1
A ***
1
A ***
1
A***
1
A***
1
A***
1
A***
1
A***
1
A***
1
A***
1
A ***
1
A ***
1
B ***
1
A ***
1
A ***
1
A ***
1
A ***
1
B ***
1
A ***
1
A ***
1
A ***
1
A ***
1
B***
1
B ***
1
B ***
1
B ***
1
B ***
1
B ***
1
B ***
1
B ***
1
A ***
1
A***
1
GB.COMPACTAHSK.210520
Adjusted value
Effect
Priority
Indication
0=Operat. 0=blockedt
1=Stop
A=A alarm
B=B alarm
1*
1*
0**
1
1
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
1
1
1
1
0
1
1
1
1
0
0
0
0
0
0
0
0
1
1
Effect
LED
0=Operat.
0=Off
1=Stop
1=On
www.swegon.com
61
