READINGS

The operating status and the values can be read. Used for
performance checks and for generally checking values,
settings, power consumption, etc.
No values can be altered in this menu group.
Each menu indicates which values can be read.
The operation times per 24 hour period are given under
the OPERATION TIME menu.
12

MANUAL TEST

Note! Manual test running can cause indoor com-
fort problems. There is also risk of overloading the
system. The responsibility for discomfort and over-
load rests totally on the person who activates the
function.
Manual test run can take place for testing the inputs and
outputs, fans and heat exchanger, etc.
Used when the air handling unit is first installed to make
sure that all the connections have been correctly wired.
Most alarms, functions and normal control modes will be
blocked while manual testing is in progress.
On a return to the other menu groups, the controller
resumes normal operation and all settings for manual test-
ing will be terminated.
Each menu indicates which functions can be test run.
38 www.swegon.com
INSTALLATION
INSTALLATION
Registered design. The company reserves the right to make design changes without prior notice.
GB.COMPACTAHSK.210520

READINGS
