Swegon COMPACT Air Operation And Maintenance Instructions page 47

Alarm text
Function
103 HEATING VALVE I/O-7 DEFECTIVE
Controls of the Heating valve do not obtain the
same signal on AI 2 as on AU2 on I/O-module
104 COOL. CIRCUIT PUMP I/O-7 TRIPPED.
Controls of the cooling circuit pump do not obtain
correct signal according to set function.
105 HEAT. CIRCUIT PUMP I/O-7 TRIPPED
Controls of the heating circuit pump do not ob-
tain correct signal according to set function.
106 COOLING WATER TEMP I/O-7 BELOW SET POINT
Temperature for cooling water control on I/O
module is continuously 7°C below its current set
point.
107 HEATING WATER TEMP I/O-7 BELOW SET POINT.
Temperature for heating water control on I/O
module is continuously 7°C below its current set
point.
108 COOLING WATER TEMP I/O-7 ABOVE SET POINT
Temperature for cooling water control on I/O
module is continuously 7°C above its current set
point.
109 HEATING WATER TEMP I/O-7 ABOVE SET POINT
Temperature for heating water control on I/O
module is continuously 7°C above its current set
point.
110 COOLING WATER TEMP SENSOR I/O-7 DEFECTIVE
Obtained if the cooling water temperature sensor
temp is not connected or is defective.
111 HEATING WATER TEMP SENSOR I/O-7 DEFECTIVE
Obtained if the heating water temperature sensor
is not connected or is defective.
160 NO COMMUNICATION VOC SENSOR
The air handling unit's control unit cannot estab-
lish correct communication with the VOC sensor.
161 INTERNAL COMM.-ERRO VOC SENSOR
The air handling unit's control unit cannot estab-
lish correct communication with the VOC sensor.
162 INTERNAL ERROR VOC SENSOR
VOC sensor defective.
163 VOC LEVEL BELOW/ABOVE ALARM LIMIT
The VOC sensor has read a level below or above
the set point alarm limit for more than 60 sec-
onds.
*** Blocked if the hand terminal does not display the main menu.
**** Adjustable: 0-99 months.
Registered design. The company reserves the right to make design changes without prior notice.
Priority Stop
0=blocked 0=In operat.
A=A alarm 1=Stop
B=B alarm
A*** 1
B*** 1
A*** 1
B*** 1
A*** 1
0*** 1
0*** 1
B 1
A 1
B 0
B 0
B 0
B 0
GB.COMPACTAHSK.210520
Indication Delay
LED
0=Off s=seconds
1=On m=minutes
0 10 m
0 30 s
1 30 s
0 30 m
0 30 m
0 30 m
0 30 m
0 3 s
0 3 s
1 10 s
1 60 sec.
1 60 sec.
1 60 sec.
www.swegon.com
Resetting
M=manual
A=automatic
M
M
M
M
M
M
M
A
A
A
A
A
A
