CONTROL DISPLAY

14.1 Language

The language desired can be set here. Normally this set-
ting is entered when the air handling unit is started for the
first time and the question ÄNDRA/CHANGE? automati-
cally appears in the control display.
However, the language setting can be changed at any
time.
Settings:
Value Setting
range
Language Current languages
is listed in the menu.

14.2 Air flow unit

The air flow unit desired can be set here.
Settings:
Value
Flow unit

14.3 Min/Max Adjustment

Used for restricting the setting range at user level for set-
points as well as for min. and max. temperature limits.
Settings:
Value
For ERS regulation 1
Breakpoint, min
Breakpoint, max
EA/SA Diff, min
EA/SA Diff, max
EA = Extract air
SA = Supply air
ERS= Extract air temperature-related supply air temperature-
regulation
40 www.swegon.com
Factory
settings
English
Setting Factory
range settings
l/s m3/s
m3/s
m3/h
Setting Factory
range settings
12-26°C 15°C
12-26°C 23°C
1-7°C 1°C
1-7°C 5°C
Registered design. The company reserves the right to make design changes without prior notice.
INSTALLATION
CONTROL DISPLAY

14.4 Base Settings

Used for saving and resetting the settings.
BASE SETTINGS 1 and 2 are two levels where the user
him-/herself saves current settings and activates them
when needed.
The two base settings can be used as a summer setting
and as a winter setting of the air handling unit.
The values in INITIAL SETTING 1 and 2 saved in the internal
memory can be transferred to the external MMC memory
by entering SAVE SETTINGS. EXTERNAL MEMORY.
The values can be transferred from the external MMC
memory to the internal memory by entering FETCH EX-
TERNAL MEMORY.
INITIAL SETTING 1 and 2 must be downloaded into the
control unit by entering INTERNAL MEMORY, LOAD NEW
SETTINGS.
Under SAVE EXTERNAL MEMORY, there is a function that
can save current settings to the MMC memory.
Current settings can be stored directly in the control unit
under FETCH EXTERNAL MEMORY
FACTORY SETTINGS resets the air handling unit's settings
to the original values it had when it was supplied (See
21.1 Commissioning Record).
The preset values for communication and alarm priority
are not reset if the factory settings are reinstated.
Settings:
Value
Save/fetch setting
Save setting – internal memory Save new setting 1
external memory Save setting 1
Load/fetch – internal memory
external memory
Factory setting
GB.COMPACTAHSK.210520
*CONTROL DISPLAY*
LANGUAGE
AIR FLOW UNIT
MIN/MAX SETTING
BASE SETTINGS
Setting range
Save new setting 2
Save setting 2
Save current setting
Save all
Load new setting 1
Load new setting 2
Fetch setting 1
Fetch setting 2
Fetch current setting
Fetch all
Activate
