21.2 Declaration of Conformity

For Declaration of Conformity, see our home page at
www.swegon.com.

21.3 Ecodesign data

The air handling unit complies with the directives
2009/125/EC and 2014/53/EU.
Data for directive 2014/53/EU is available for sizing in the
product selection software AHU Design.
Data for directive 327/2011/EU according to below.
Air Handling Units (including GOLD-E), EU regulation 327/2011 all fan data
Datum: 2020-03-23
AHU data Fan data
Impeller
Motor Impeller
Type Size diameter
option type
mm
COMPACT
2 - ebm-papst 250
Unit, Top
3 - ebm-papst 250
Air ,Heat
Registered design. The company reserves the right to make design changes without prior notice.
Motor
Motor Installation Efficiency
power
manufacture category category
kW
ebm-papst 0,23 A Static
ebm-papst 0,40 A Static
Data according to ErP directive in technical documentation and free access webpage
Vaiable
Specific Overall efficiency η
e(s)
speed
ratio
drive
Actual Req 2015
Yes 1,00 65,5 44,4
Yes 1,00 66,7 47,2
GB.COMPACTAHSK.210520
Power Air Flow
Efficiency grade N
input P q increase p
ed v
Actual Req 2015 kW m³/s
83,1 62 0,210 0,400
81,5 62 0,393 0,500
www.swegon.com
Pressure
Speed n
fs
Pa minˉ¹
303 2250
470 2800
