Swegon COMPACT Air Operation And Maintenance Instructions page 60

Function
External alarms
Time delay Alarm 1 (s)
Alarm on closure, Alarm 1
Alarm reset
Time delay Alarm 2 (s)
Alarm on closure, Alarm 2
Alarm reset
Alarm limit temperature
Deviation SA setpoint
Min. EA temperature
Filter function
Filter alarm limit
SA (%/Pa)
EA (%/Pa)
H EXCH defrosting
Alarm limit (Pa)
Service period
Alarm limit (month)
Alarm priority See the following pages
Control display setting
Language
Flow unit
Min./max. setting
Break point, ERS Regulation (Control) (°C)
Difference SA/EA (°C)
Initial setting
Communication
EIA-485
Protocol
Address
Speed
Parity
Stop bit
Ethernet
Mac Id
DHCP server
IP address
Port no.
Net mask
GateWay
DNS server
NO. 1
NO. 2
Modbus TCP
IP address
Port no.
Net mask
BACnet IP
Funktion
Device ID
Port nr.
The values refer to the sizes in due succession: 02, 03.
1) Applies to COMPACT Heat only
2) Only in combination with Cooling BOOST. 0,2 m3/s, 0,3 m3/s.
3) Only in combination with Demand control. 0,08 m3/s, 0,08 m3/s.
4) Possible options: Control of outdoor air/exhaust air damper, in-operation indication, low speed operation indication, indication or high speed
operation, group alarm A, group alarm B, control of external heating, control of external cooling.
5) Possible options: External stop, external low speed operation, external high speed operation, external alarm 1, external alarm 2, external reset,
external heating, external fire alarm.
6) 0,1 m3/s, 0,25 m3/s.
7) 0,1 m3/s, 0,15 m3/s.
8) 0,15 m3/s, 0,25 m3/s.
9) Same setting in both Morning Boost and Heating.
60 www.swegon.com
Factory-preset value
10
1
X Man. Auto
10
1
X Man. Auto
5,0
15,0
10/100
10/100
50
12
-
English
l/s X m /s
3
15,0/23,0
1,0/5,0
–
Modbus RTU
1
PLA (Exoline) 1
ELA (Exoline) 1
9600
None
1
Individual
Inactive
10.200.1.1
80
255.0.0.0
000.000.000.000
000.000.000.000
000.000.000.000
000.000.000.000
502
000.000.000.000
Ej aktiv
0000000
47808
Registered design. The company reserves the right to make design changes without prior notice.
GB.COMPACTAHSK.210520
Adjusted value
Man.
Man.
m /h l/s
3
Auto
Auto
m /s m /h
3 3
