Access Point Bracket Usage and Mounting Options

Procedure
1. If you have ordered the AP560h access point separately, verify that the box contains the following
items:
Quantity
1
1
2. If you have ordered the service panel separately (EIO-03-SP), verify that the box contains the
following items:
Quantity
1
1
4
What to Do Next
After verifying the box contents, ensure that you have all the necessary parts to begin your preferred
installation.
Access Point Bracket Usage and Mounting Options
Details about various mounting brackets and accessories that can be used with the access point during
wall or pole installation.
The access point is mounted on a wall or to a pole, the details of which are described in the following
table:
Table 7: AP560h mounting brackets and accessories usage
Mounting bracket/
accessory and part
number
KT-147407-02 bracket;
comes with three
bracket parts
KT-150173-01; extension
arm; used with
KT-147407-02 bracket
parts
14 ExtremeWireless™ AP560h Access Point
Item
AP560h Quick Reference
AP560h access point
Item
Plastic service panel base
Plastic service panel top with one captive screw
75mm long service panel shoulder screws
Wall install
Yes
Yes; place the
KT-150173-01 extension
arm on top of the 1-axis
KT-147407-02 tilt part
Pole install
Yes
Yes; attach the
KT-147407-02 pole part
to the extension arm
Install the Access Point
Notes
For attaching to a wall
or a flat surface, use the
bracket part that has
two holes metal surface.
For attaching to a pole,
attach the
KT-147407-02 pole part
on top of the 1-axis tilt
part.
None.
