AP560h Overview

AP560h Features

Purchase Order Information
The AP560h is a Wi-Fi 6, 802.11ax/ac/abgn outdoor access point. The access point caters to the
stadium environment by supporting high density of users and devices. It offers flexible deployment
options and can be mounted to a pole, and to a wall, thereby ensuring exceptional mobile experience
throughout the stadium.
The AP560h access point is sold separately, and all brackets and accessories must be purchased
separately.
Note
The AP560h-FCC access point requires a minimum base firmware of WiNG 7.1.2.
Note
AP560h-WR access point requires a minimum base firmware of WiNG 7.2.1.0-015R.
AP560h Features
The AP560h access point has the following features:
•
Radios: Two radios
◦ 1 dual-band, 2.4GHz and 5GHz, and 1 band-locked 5GHz
◦ 1 IoT Radio (2.4 GHz)
•
Two Ethernet ports
◦
1 x 100/1000/2500/5000 Mbps auto-negotiation Ethernet port, RJ45
◦ 1 x 10/100/1000 Mpbs auto-negotiation Ethernet port, RJ45
•
Dimensions: 11.3 in. × 18.9 in. × 3.5 in. (288 mm × 481 mm × 88 mm)
•
LEDs: Two top-mounted LEDs – all LEDs will be on during reset.
•
One Reset button
•
Security locks:
◦ One hole for security hanger lock
•
Power: PoE 802.3at
•
Antennas:
◦ Two software selectable internal antennas (30 degree and 70 degree directional antennas)
