Install the Access Point
Two M12 screws
Two M12 hex nuts
0.5 in. wide stainless-steel cable clamps
KT-150173-01 extension arm
Note
You must provide M6 hex-head screws and screw-in anchors.
Install the Access Point on a Pole Using MBO-ART02 Articulating Mounting Bracket
and POLE01 Bracket
About This Task
Attach the access point to a pole using the WS-MBO-POLE01 bracket on MBO-ART02 articulating
mounting bracket.
Table 9: Hardware requirements for pole installation
Quantity
1
1
2
1
4
2
Note
You must provide stainless-steel cable clamps. The band must be 0.5 in. (12.7 mm) wide.
Procedure
1. Attach the MBO-ART02 articulating mounting bracket to the access point using two M6 hex-head
screws.
Install the Access Point on a Pole Using MBO-ART02
Articulating Mounting Bracket and POLE01 Bracket
Item
Access point
MBO-ART02 articulating mounting bracket
M6 hex-head screws to attach the MBO-ART02 to the access point
WS-MBO-POLE01 bracket
M3 screws with nuts and washers to attach the WS-MBO-POLE01
bracket to the MBO-ART02 articulating mounting bracket
Cable clamps
ExtremeWireless™ AP560h Access Point
23
