Install the Access Point Using MBO-ART02 Articulating
Mounting Bracket
•
KT-150173-01 extension arm (see
•
Six M6 screws
•
Four M6 size hex-head screws
•
Screw-in anchors if the access point is being mounted on a wood wall or a concrete surface.
Note
The M6 hex-head screws and screw-in anchors must be provided by the installer.
If you install the access point to the wall using the ART02 bracket, use the following hardware:
•
One access point
•
MBO-ART02 articulating mounting bracket
•
Six M6 hex-head screws
◦ Two M6 hex-head screws to attach the bracket to the access point
◦ Four M6 hex-head screws to attach the bracket to the wall or a flat surface.

Install the Access Point Using MBO-ART02 Articulating Mounting Bracket

About This Task
Table 8: Hardware requirements for MBO-ART02 articulating mounting bracket wall
installation
Quantity
1
1
6
Note
When using the MBO-ART02 articulating mounting bracket, set the minimum downward tilt
to less than 20 degrees to prevent water ingress. If you keep the tilt to more than 20 degrees,
a service panel (EIO-03-SP) must be installed to protect the glands on the access point.
For installation instructions on how to install the service panel, see
the Access Point
To install the access point on a wall:
16 ExtremeWireless™ AP560h Access Point
Figure 7
Item
Access point
MBO-ART02 articulating mounting bracket
M6 hex-head screws
Two M6 hex-head screws to attach the MBO-ART02 to the access
point.
Four M6 hex-head screws to attach the MBO-ART02 bracket to the
wall.
on page 32.
on page 21).
Install the Plastic Service Panels on
Install the Access Point
