DEFINITY Communications System
DEFINITY High Speed Link
User´s Guide
Appendix D: Applications and Switch Administration
PROC 321 Word 4 (Screen D-11) is used to associate a RNX
with an AAR pattern number. In this example, pseudo RNX
330 (Field 1) is associated with AAR pattern number 30 (Field
4) so that the proper digit manipulation and routing can be
performed as defined in PROC 321 Words 1, 2, and 3.
ENHANCED MODE - PROCEDURE:
AAR - ROUTING
1. Location Code (RNNX): [330]
2. Mode Number: [---]
3. Call Category: [---]
4. Pattern Number: [30]
5. First Digit: [-]
Generic 2 Routing Administration - RNX and Pattern Number Association
Note: If there are any ISDN PRI trunks defined on the Generic 2,
PROC 321 Word 5 (ISDN parameters for AAR
preferences) must be administered even though these
video calls are being routed over robbed-bit facilities. If
this is the case, PROC 321 Word 5 must be administered
such that the BCCOS (Field 5) of routing pattern 30 (Field
1) is 3. This is assuming that the default BCCOS 3 has not
been altered. If it has been altered, another BCCOS
should be defined using the default BCCOS 3 attributes.
The administration to support switched videoconferencing is now
complete. A user can now dial two numbers of the form 8-330-
XXXX to establish a video call from the Generic 2 to the Generic 1.
The 8 represents the feature access code for AAR. The 330 is used
to indicate that the call is an SDDN call so that the switch can
select trunk group 60 and replace the 330 prefix with 115331 in
order to route the call to the proper location over SDDN.
321, WORD: 4
SCREEN D-11
Page D-25
