OPERATOR'S MANUAL
TWO-ROTOR ROTARY RAKES
The original operator's manual
ENGLISH
TANGO 730
SaMASZ Sp. z o.o.
tel. (+48) (85) 664 70 31
ul. Trawiasta 1
fax (+48) (85) 664 70 41
16-060 Zabłudów
e-mail: samasz@samasz.pl
Polska
www.samasz.pl
Serial number
IN307EN003
2020-04-27
EDITION 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TANGO 730 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SaMASZ TANGO 730

Summary of Contents for SaMASZ TANGO 730

  • Page 1 SaMASZ Sp. z o.o. tel. (+48) (85) 664 70 31 ul. Trawiasta 1 fax (+48) (85) 664 70 41 16-060 Zabłudów e-mail: samasz@samasz.pl Polska www.samasz.pl OPERATOR'S MANUAL TWO-ROTOR ROTARY RAKES TANGO 730 IN307EN003 The original operator’s manual Serial number 2020-04-27...
  • Page 2 Well-proven design with thousands of machines in regular use in many countries and quality materials ensure high durability and reliability of SaMASZ rakes. We congratulate you on the purchase of your new SaMASZ rake and wish you much pleasure and the very best experience resulting from its operation.

  • Page 3: Table Of Contents

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Contents page 1. IDENTIFYING THE MACHINE ....................... 5 2. INTRODUCTION ........................5 3. PROPER USE ..........................6 3.1. Technical data ..........................6 3.2. Design and operating principle ......................7 3.3. Equipment and spare parts ........................ 7 4.
  • Page 4 TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 7.2.1. Restarting the machine after longer idle periods ..............35 8. LUBRICATION ......................... 35 8.1. Risks present when lubricating ......................35 8.2. Gear ............................... 36 8.3. Bearings and joints .......................... 37 9. RAKE REPAIR AND WITHDRAWAL FROM USE ................38 9.1.

  • Page 5: Identifying The Machine

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 1. IDENTIFYING THE MACHINE Data plate, VIN and approval plate are mounted to the rake’s main frame in the place shown in Fig. 1. *SU0TAN730K1234567* Sp. z o.o. e32*167/2013*xxxxx*xx SU0TAN730K123456 2000 kg A-0: 1200 kg...

  • Page 6: Proper Use

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 3. PROPER USE Rotary rake is designed to rake up green forage, dried forage and hay. The machine cooperates with tractors with power from 60 HP. The rake can be used only by persons familiarized with its technical characteristics, and aware of risks associated with its operation and ways to avoid these.

  • Page 7: Design And Operating Principle

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 3.2. Design and operating principle Fig. 2. Overview of two rotor rake TANGO 1 – Hitch 10 – Raking arms 2 – Linkage frame 11 – Raking tines 3, 5, 8 – PTO shafts 12 –...

  • Page 8: Safety Advice And Caution

    710-1058 7G7R071CE007WR7A Bondioli & Pavesi unidirectional PTO shafts of other brands with equivalent technical parameters may be used on the SaMASZ permission. CAUTION! Respect lubrication frequency of telescopic articulated shaft solely. Points marked in Fig. 3 shall be lubricated every 50 hours. Telescopic articulated shaft shall be lubricated prior to and after period of longer idleness also.
  • Page 9 OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 CAUTION! Keep the children away from the mower both in operation and standstill. When in standstill the machine should be protected against unauthorized use with a padlock ❑ mounted on hitch pin (Fig. 36).

  • Page 10: Qualifications Of Operator

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL Rotating spring tines and other rotary elements present a danger to health and life of persons ❑ present nearby the machine. Do not touch any moving machine parts. The operator is not allowed to leave the tractor while driving.

  • Page 11: Transport

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 4.4. Transport Before transporting the rake make sure that the support leg is lifted and protected. ❑ Before transporting the rake make sure that the locking pawls are properly latched in the transport ❑...

  • Page 12: Operating Parts

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 162'' / 4115 mm Fig. 4. Location of centre of gravity 4.5. Operating parts Prior to operating the rake check condition of both the rotor and raking tines. ❑ Worn or damaged tines should be replaced immediately with new ones.

  • Page 13: Residual Risk

    Useful life for hydraulic hoses is 5 years from their production date. ❑ 4.8. Residual risk Despite the fact, that SaMASZ company – the manufacturer of the rake takes the responsibility for the rake design and manufacturing, in order to eliminate hazard, certain risk when operating the rake is unavoidable.

  • Page 14: Bans

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL CAUTION! Residual risk results from incorrect behaviour of the rake's operator. 4.8.4. Bans Bear in mind the following bans when operating the rake: do not remove clogs from the rake, make any adjustments or repairs when the rake is operating, ❑...

  • Page 15: Safety Decals And Their Meaning

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 4.9. Safety decals and their meaning CAUTION! a) all warning decals (labels) should be clean and legible, b) lost or damaged decals (labels) must be replaced, new decals (labels) may be ordered at the manufacturer.
  • Page 16 TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL N-133 N-167 N-168 N-183 Do not drive on slopes Do not remain on the machine Do not touch the machine Caution: danger of leg where the vehicle is likely while driving before the rotating parts have...
  • Page 17 OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 N-52 N-100 N-101 N-102 Use protective gloves Use eyes protection Use protective clothing Use safety helmet N-103 N-104 Use ears protection Use protective footwear N-200 N-182 N-202 N-41 N-15; N-82; N-162 N-52; N-100; N-101 N-102;...

  • Page 18: Using The Rake

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 5. USING THE RAKE 5.1. Mounting rake on tractor CAUTION! When attaching the rake, there should be no persons between the machine and the tractor. Any accidental manoeuvring with the aggregate might cause crushing of unauthorized personnel.

  • Page 19: Preparing Rake For Transport

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 CAUTION! once diode (2) lights up the function remains active for 60 seconds. This time is sufficient to fold the machine to transport position or unfold it to working position. As the 60 s time elapses the panel will go to sequential operation mode.

  • Page 20: Mounting Telescopic Articulated Shaft

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL CAUTION! Once the machine is set to transport position, check whether mechanical locking pawls (P) are properly locked on pins (Fig. 10). Fig. 10. Rake in transport position 5.2.1. Preparing rake for transport on public roads To meet safety precautions concerning transport on the public roads the rake should be equipped with warning triangle, attached at the rake's rear (the plates are standard-delivered with the machine.)

  • Page 21: Shortening Pto Shaft

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 CAUTION! Prior to the operation commencement, read the operator's manuals of both the machine and the PTO shaft. Safety guards should be inspected whether they (in the tractor, the mower and the PTO shaft) are placed correctly and are not damaged.

  • Page 22: Switching The Rake From Transport To Working Position

    5.5. Preparing rake for operation CAUTION! For the machine storing period, cylinder rods are lubricated as SaMASZ with protective grease in order to protect them against weather conditions able to shorten their service life. Prior to start operating the machine remove excess grease coming out from cylinder rods.
  • Page 23 OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Fig. 15. Temporary mounting of arms Fig. 16. Supporting rake arm hammer expansion pins into holes where bolts were previously placed. put pin Ø10 and Ø6 into ❑ each one hole (Fig. 16).

  • Page 24: Raking Height Adjustment

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL The following should be performed in workplace and as rake is in working position: connect PTO shaft extension onto tractor's spline shaft (if only one extension was taken out) or ❑ connect the complete PTO shaft, set the tractor and rake aggregate on an even, level ground, ❑...

  • Page 25: Working Width Adjustment

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 trolley's pin (6) should be located in upper sleeve (7), ❑ left (8) and right (9) arm to be switched analogically. ❑ SUPPORT Fig. 21. Increasing raking height with driving trolley Fig. 22. Trolley's height in a) normal setting, b) increased setting 5.5.2.

  • Page 26: Operation

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL CAUTION! Manual regulation of rake’s working width (arms lifted up). Hydraulic extension can be done in transport as well as on headlands (Fig. 34). 5.6. Operation Rotary rake is used for raking up swath or grass after tedders. The driving speed should be the result of ground configuration, quantity of grass, and raking cleanness.
  • Page 27 OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Fig. 26. Lifting front tarpaulin cover Fig. 27. Securing lifting mechanism move away the rear tarpaulin cover from raking arms for a required distance, and secure against ❑ retracting with clamps (D) (Fig. 28), Fig.

  • Page 28: Switching Rake From Forming One To Forming Two Single Rows

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 5.6.2. Switching rake from forming one to forming two single rows In order to switch the machine for raking two rows, perform the following: fold out working assemblies with tractor's hydraulics, so that raking tines on front working ❑...

  • Page 29: Sequential Lifting

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Due to the rake's design, where working units are arranged in different distances in relation to the tractor, a mechanism for sequential lifting and lowering of working units is applied, and it is used when driving the machine to and from a meadow.

  • Page 30: Protection Mechanism Of Front Safety Curtain

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 5.8. Protection mechanism of front safety curtain The mechanism is designed to provide protection of front safety curtain against damage in the event the curtain was not locked in the upper position by shut-off valve, and the rotating working units will be slid down.

  • Page 31: Removing Clogging And Jams

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Fig. 35. Rake in position for headlands CAUTION! When preparing the rake for position for headlands, there is a risk of tilting and falling of the aggregate, thus this should be carried out on an even ground.

  • Page 32: Mounting And Adjustments

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL Detach the machine from the tractor, ❑ Secure hitch pin with a padlock (Fig. 36). ❑ Fig. 36. Protection against unauthorized use 6. MOUNTING AND ADJUSTMENTS 6.1. Installing tines Tines should be installed according to scheme provided in Fig. 37.

  • Page 33: Wheel Replacement

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Once pins are removed slide down arm mount from connecting rod, ❑ Loosen four screws (S) that fix connecting rod to gearbox body, ❑ Remove damaged connecting rod module, ❑ Install new connecting rod, ❑...

  • Page 34: Maintenance

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL Fig. 39. Points of mounting of lifter 7. MAINTENANCE Before any maintenance works follow remarks and warnings on safety as given in subsection 4.1. Safety rules and regulations. CAUTION! Before any maintenance works detach the machine from the tractor.

  • Page 35: Restarting The Machine After Longer Idle Periods

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 7.2.1. Restarting the machine after longer idle periods After longer idle periods: inspect its technical condition with special attention paid to hydraulic and drive systems, ❑ paint the area affected, ❑ lubricate the parts and units, ❑...

  • Page 36: Gear

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 8.2. Gear On daily basis prior to work commencement check the oil level and, if needed, refill. The oil level can be checked by the check opening B (Fig. 40). If the oil level is too low, refill the oil until it is visible in the check opening B.

  • Page 37: Bearings And Joints

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 8.3. Bearings and joints Every 50 hours of rake’s operation, pay attention to lubricating rear wheel legs and trolley (Fig. 42) with grease ŁT43 (or other lubricant designed for lubricating rolling and sliding bearings, which are exposed to operating in temperatures between -30°C and +130°C).

  • Page 38: Rake Repair And Withdrawal From Use

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 9. RAKE REPAIR AND WITHDRAWAL FROM USE 9.1. Repair CAUTION! Prior to commencing repair works the machine should be disconnected from the tractor. Prior to approaching any repair or service works clean the machine thoroughly and remove any possible grass, dirt or mud remaining after raking.

  • Page 39: Possible Defects And Their Repairs

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 10. POSSIBLE DEFECTS AND THEIR REPAIRS Defect type Cause Recommendations Damaged or soiled elements of hydraulic Replace or clean fastening elements of assembly hydraulic assembly The working parts will not Examine condition of tractor's hydraulic...

  • Page 40: Warranty Card

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 11. WARRANTY CARD ROTARY RAKE Serial number Date of manufacture Manufacturer stamp Date of purchase Dealer stamp Dealer signature The product quality has been checked and meets the required standards and regulations and is permitted for use.
  • Page 41 CAUTION! The SaMASZ company is constantly working on the development of all of its machine types and models. Therefore, there is always a possibility in change of form, equipment and technology of the delivered machines. No claims can arise from data, drawings and descriptions included herein as well as the spare part list.

  • Page 42: Warranty Repairs Record

    TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL 12.2. Warranty repairs record Repairs scope and spare parts replaced: Date, stamp and signature of repair shop. Date, stamp and signature of repair shop. Date, stamp and signature of repair shop.

  • Page 43: Attachment 1. Electric And Hydraulic Schemes

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Attachment 1. ELECTRIC AND HYDRAULIC SCHEMES 1) Electric scheme of the lighting...
  • Page 44 TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL Hydraulic scheme...

  • Page 45: Attachment 2. Defining The Total Weight, Axis Load, Tyre Load Capacity And Minimum Load

    OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730 Attachment 2. DEFINING THE TOTAL WEIGHT, AXIS LOAD, TYRE LOAD CAPACITY AND MINIMUM LOAD CAUTION! When mounting the machine on a tractor using front and/or rear 3-point linkage, a maximum value of permissible load cannot be exceeded – tractor's front axis load must be 20% of the tractor's overall weight.
  • Page 46 TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL Calculating minimum weight of front balast M – machine mounted at tractor's rear: ❑ P min. �� × ( �� + �� ) − �� × �� + 0,2 × �� × ��...
  • Page 47 OPERATOR’S MANUAL TWO-ROTOR ROTARY RAKE TANGO 730...
  • Page 48 TANGO 730 TWO-ROTOR ROTARY RAKE OPERATOR’S MANUAL SaMASZ Sp. z o.o. tel. (+48) (85) 664 70 31 ul. Trawiasta 1 fax (+48) (85) 664 70 41 16-060 Zabłudów e-mail: samasz@samasz.pl Polska www.samasz.pl...
