OPERATOR'S MANUAL
TWO-ROTOR RAKE
TANGO 730
Serial number
Translation of the original operator's manual
SaMASZ Sp. z o.o.
Poland, 16-060 Zabłudów, ul. Trawiasta 1
– English –
Established – 1984
NIP PL-966-159-29-76
tel. (+48) (85) 664 70 31
fax (+48) (85) 664 70 41
e-mail: samasz@samasz.pl
www.samasz.pl
IN307USA002
2019.06.28
EDITION 2
