3. Mounting

1) Piping
- Flush the piping before connecting the piping
- Confirm the IN and the OUT before piping. The product should not be used with the wrong connection.
(IN and OUT direction should be identified by the IN mark indicated on the case.)
- Tighten the product to the recommended torque.
- Confirm that chips from the pipe threads and sealing material do not enter the piping.
Also, when sealant tape is used, leave 1.5 to 2 thread ridges exposed at the end of the threads.
Note) Confirm that there is enough space for maintenance before installing and piping this product.
2) Operation
- Flush the piping line before the starting actual operation when the filter is used for the first time or has
been replaced.

4. Element Replacement

The replacement time for elements is when one of the following conditions occurs.
1) After 1 year of usage has elapsed.
2) When the pressure drop reaches 20 kPa even though the operating period has been less than 1 year.
< Replacement Element Part No. >
Part No.
EJ001H-030N
EJ101H-030N
< Replacement Gasket Part No. >
Part No.
AL-204H
AL-205H
Applicable
Element Size
filter model
ZFA100 43 x 42 x 12
ZFA200 43 x 40 x 22
Applicable
filter model
ZFA100
ZFA200
Set description
-10-
Element
Element
