SMC Networks AC10 A Series Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NAME
AIR COMBINATION
MODEL/ Series
AC10(A,B)-
AC20(A,B,C,D)-
AC25(B,C)-
AC30(A,B,C,D)-
AC40(A,B,C,D)-
AC50(A,B)-
※
AC55(B)-
AC60(A,B)-
※
-A
※
-B
※
-B
※
-B
※
-B
※
-B
-B
※
-B
Doc. No. AC-OMT0014-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC10 A Series and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks AC10 A Series

Summary of Contents for SMC Networks AC10 A Series

  • Page 1 Doc. No. AC-OMT0014-A PRODUCT NAME AIR COMBINATION MODEL/ Series ※ AC10(A,B)- ※ AC20(A,B,C,D)- ※ AC25(B,C)- ※ AC30(A,B,C,D)- ※ AC40(A,B,C,D)- ※ AC50(A,B)- ※ AC55(B)- ※ AC60(A,B)-...

  • Page 2: Table Of Contents

    Contents PAGE 1. PRECAUTION FOR SAFETY 1～8 2. APPLICATION SPECIFICATIONS. . 4. SERIESMAP AND COMBINATION OF EQUIPMENT. . 5. HOW TO ORDER 11～18 6. ATTACHMENTS / ACCESSORIES（OPTIONS）PART NUMBER 7. TROUBLE SHOOTING 8. SPARE PARTS LIST 9. HOW TO REPLACE 10. DISASSEMBLY DRAWING 21～22 11.
  • Page 3 AIR COMBINATION Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC), 1) 2) Japan Industrial Standards (JIS)
  • Page 4 AIR COMBINATION Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
  • Page 5 Precautions for design ！ WARNING ○ Air combination ① Consult SMC if no leakage is allowed due to the environment, or operating fluid is not air. ② External parts including the bonnet (material: polyacetal), bowl, sight dome (material: polycarbonate) are made of resin. Organic solvents including synthetic fluid, chemicals including acetone, alcohol, ethylene chloride, sulphuric acid, nitrate, hydrochrolic acid, cutting oil, kerosene, gasoline, lock material of screw are harmful.
  • Page 6 ○ Air filter, Lubricator, Filter-regulator and Mist separator ① Avoid the application where charge and discharge of pressure to bowl is switched frequently. This may damage the bowl. A metal bowl is recommended in these cases. ○ Regulator and Filter-regulator ①...
  • Page 7 Installation ！　　WARNING ○ Air combination ① Connect the product ensuring the direction of " １ " (IN) and " ２ " (OUT) for air direction or an arrow. Wrong connection may cause malfunction. ② Install with enough space around each assembly component to perform regular maintenance and operation.
  • Page 8 ⑥ Outlet pressure may change if filter regulator is used for long periods. Please confirm set pressure regularly. Piping ！　　WARNING ○ Air combination ① Blow out or clean piping before piping to eliminate swarf, cutting oil, solid foreign material. Contamination of piping may cause damage or malfunction. ②...
  • Page 9 ○ Air filter, Lubricator, Filter-regulator and Mist separator ① Perform periodical check to find cracks, flaw or other deterioration on the resin parts such as bowl or sight dome. If any of these are seen, a malfunction has occured, replace with new parts.
  • Page 10 ○ Lubricator ① Check the dripping amount once a day. Dripping failure may cause damage to lubricated objects. ② Use clean oil to avoid dripping failure. ③ The lubricating amount should be less than the upper limit of oil level. ④...

  • Page 11: Application

    ２．ＡＰＰＬＩＣＡＴＩＯＮ This product is used in combination with components which aim to eliminate a certain amount of water vapour and solid foreign material in the air line, lubricating and pressure controlling pneumatic products or solenoid valves. ３．ＳＰＥＣＩＦＩＣＡＴＩＯＮＳ Model AC10*-A AC20*-B AC25*-B AC30*-B AC40*-B...

  • Page 12: Seriesmap And Combination Of Equipment

    ４．ＳＥＲＩＥＳＭＡＰ　ＡＮＤ　ＣＯＭＢＩＮＡＴＩＯＮ　ＯＦ　ＥＱＵＩＰＭＥＮＴ ×：None applicable model * ： Symbol Model (AC20C～40C-06-B) (AC20D～40D-06-B) (AC10-A／AC20～60-B) (AC10A-A／AC20A～60A-B) (AC10B-A／AC20B～60B-B) AF10-A ＋ AW10-A AF10-A × × 　　AC10*-A AR10-A ＋ ＋ ＋ AL10-A AR10-A AL10-A AF20-A AF20-A ＋ AW20-B AF20-A ＋ AW20-B 　　AC20*-B AR20-B ＋ ＋ AFM20-A ＋ ＋...

  • Page 13: How To Order

    ５．ＨＯＷ　ＴＯ　ＯＲＤＥＲ ・Option / Semi-standard : Select one each for a to h. AC 10 - M5 ・Option / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC10-M5CG-T-12NR-A Symbol Description Without auto drain Float type auto drain Ｃ...
  • Page 14 ・Option / Semi-standard : Select one each for a to m. 03 DE AC 30 - ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC30-F03DE1-KSTV-136NR-B Symbol Description Body size Ｒc ●...
  • Page 15 ・Option / Semi-standard : Select one each for a to h. AC 10 A - M5 ・Option / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC10A-M5CG-T-12NR-A Symbol Description Without auto drain Float type auto drain Ｃ...
  • Page 16 ・Option / Semi-standard : Select one each for a to l. 03 DE AC 30 ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC30A-F03DE1-KSV-136NR-B Symbol Description Body size Ｒc ●...
  • Page 17 ・Option / Semi-standard : Select one each for a to g. AC 10 B - M5 ・Option / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC10B-M5CG-T-12NR-A Symbol Description Without auto drain Float type auto drain Ｃ...
  • Page 18 ・Option / Semi-standard : Select one each for a to j. 03 DE AC 30 ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC30B-F03DE1-SV-16NR-B Symbol Description Body size Ｒc ●...
  • Page 19 ・Option / Semi-standard : Select one each for a to j. 03 DE AC 30 ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC30C-F03DE1-SV-16NR-B Symbol Description Body size Ｒc ●...
  • Page 20 ・Option / Semi-standard : Select one each for a to j. 03 DE AC 30 ・Option / Attachment / Semi-standard symbol : When more than one specification is required, indicate in alphanumeric order. Example） AC30D-F03DE1-SV-16NR-B Symbol Description Body size Ｒc ●...

  • Page 21: Attachments / Accessories（Options）Part Number

    6. ATTACHMENTS / ACCESSORIES （OPTIONS） PART NUMBER Attachments / Accessories (Options) part number Model Descriptio For AC10*-A For AC20*-B For AC25*-B For AC30*-B For AC40*-B For AC50*-B For AC55*-B For AC60*-B For AC40*-06-B Note1) Standard G27-10-R1 G36-10-□01 G46-10-□01 Round type G27-10-R1 G36-4-□01 G46-4-□01...

  • Page 22: How To Replace

    ９．HOW　TO　REPLACE ！　WARNING ・Before replacement, ensure that the air combination assembly is not pressurized. ・Rotate the pressure adjusting handle of the regulator and filter-regulator to zero. ・Replace refering to "10. DISASSEMBLY DRAWING" (P21 to P22). ・After replacement, ensure that specified function is satisfied and external leakage is not found before starting operation. ○　Air combination Process Procedure...

  • Page 23: Disassembly Drawing

    １０．DISASSEMBLY DRAWING １） Ｆ．Ｒ．Ｌ　Combination...
  • Page 24 ２）Spacer with bracket Bracket Spacer assembly Bolt Retainer ①Packing ３）Spacer Spacer assembly Bolt Retainer ①Packing...
  • Page 25 １１．DIMENSIONS １） ＡＣ１０－Ａ ／ ＡＣ２０－Ｂ to ＡＣ６０－Ｂ ＡＣ１０－Ａ ＡＣ２０－Ｂ ＡＣ２５－Ｂ to ＡＣ６０－Ｂ Standard specifications Bracket mount Model ― ― M5×0.8 AC10-A 1/16 59.9 25.5 12.5 24.5 ― AC20-B 1/8 126.4 87.6 35.9 41.6 28.5 2 Note) 43.2 1/8・1/4 ― AC25-B 1/8 167.4 115.1 38.1 55.1 27.5...
  • Page 26 ２） ＡＣ１０Ａ－Ａ ／ ＡＣ２０Ａ－Ｂ to ＡＣ６０Ａ－Ｂ ＡＣ１０Ａ－Ａ ＡＣ２０Ａ－Ｂ ＡＣ３０Ａ－Ｂ to ＡＣ６０Ａ－Ｂ Standard specifications Note) Bracket mount Model ― ― AC10A-A M5×0.8 1/16 59.9 47.4 12.5 24.5 ― AC20A-B 83.2 87.6 72.4 41.6 28.5 1/8・1/4 ― AC30A-B 1/8 110.2 115.1 85.6 55.1 29.4 1/4・3/8...
  • Page 27 ３） ＡＣ１０Ｂ－Ａ ／ ＡＣ２０Ｂ－Ｂ to ＡＣ６０Ｂ－Ｂ ＡＣ１０Ｂ－Ａ ＡＣ２０Ｂ－Ｂ ＡＣ２５Ｂ－Ｂ to ＡＣ６０Ｂ－Ｂ Standard specifications Bracket mount Model ― ― AC10B-A M5×0.8 1/16 59.9 12.5 24.5 ― AC20B-B Note) 83.2 87.6 26.5 41.6 28.5 2 1/8・1/4 ― AC25B-B 1/8 110.2 115.1 55.1 27.5 1/4・3/8 ―...
  • Page 28 ４） ＡＣ２０Ｃ－Ｂ to ＡＣ４０Ｃ－Ｂ ＡＣ２０Ｃ－Ｂ ＡＣ２５Ｃ－Ｂ to ＡＣ４０Ｃ－０６－Ｂ Standard specifications Bracket mount Model ― AC20C-B 1/8 126.4 87.6 26.5 41.6 28.5 43.2 1/8・1/4 Note) ― AC25C-B 1/8 167.4 115.1 55.1 27.5 57.2 1/4・3/8 ― AC30C-B 1/4・3/8 1/8 167.4 115.1 30.7 55.1 29.4 57.2...
  • Page 29 ５） ＡＣ２０Ｄ－Ｂ to ＡＣ４０Ｄ－Ｂ ＡＣ２０Ｄ－Ｂ ＡＣ３０Ｄ－Ｂ to ＡＣ４０Ｄ－０６－Ｂ Standard specifications Note) Bracket mount Model ― AC20D-B 1/8・1/4 83.2 87.6 72.4 41.6 28.5 ― AC30D-B 1/8 110.2 115.1 85.6 55.1 29.4 1/4・3/8 ― AC40D-B 1/8 145.2 147.1 91.7 38.4 72.6 33.8 1/4・3/8・1/2 ―...
  • Page 30 Revision history Ａ P5 Installation CAUTION Air combination ③ is added. July 2018 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
