SMC Networks ZFA100- 02 Series Operation Manual page 10

2) Manifold
Model
ZFA100
ZFA200
Note) The left and right brackets are mounted on the air suction filter single unit.
Model
Single
Symbol
Note)
unit
2
L1 38 56
L2 50 68
L1 48 76
L2 60 88
Symbol
Port size
ZFA100 1/8
ZFA200 1/4
Number of manifold stations
3 4 5
74 92 110 128 146 164 182 200
86 104 122 140 158 176 194 212
104 132 160 188 216 244 272 300
116 144 172 200 228 256 284 312
-9-
A
19
24
6 7 8 9
B
18
28
10
