5. Remove the Antistatic hose from the connector for the Antistatic hose in PHS
6. Connect a PVC brush to the pulled end of the Antistatic hose.
7. Check that the grounding of your ATEX Vacuum Cleaner is properly installed.
8. Turn on the vacuum cleaner and clean the Powder Feeding Screw
contents of the vacuum cleaner as waste for disposal (image 54).
9. After the work is finished, install the Powder Feeding guards back in the Chambers
10. Re-install both grids on the Chambers
11. Connect the Antistatic hose back to the connector for the Antistatic hose in the PHS
12. Reconnect the power supply to the PHS.
C. CLEANING THE INTERIOR OF THE PHS DEVICE
Allen key 5 mm
1. Operate only when the power is off! Also, switch on the E-STOP button
the internal components of the machine.
2. Using an Allen key 5 mm, unscrew the back service panels. Each panel holds 2 screws (image 55) on top. Put the
panels in a safe place.
3. Remove the Antistatic hose from the connector for the Antistatic hose in PHS
4. Connect a PVC brush to the pulled end of the Antistatic hose.
5. Check that the grounding of your ATEX Vacuum Cleaner is properly installed.
6. Turn on the vacuum cleaner and clean the interior of the device. When vacuuming, pay attention to the electrical
installation and grounding. Treat the contents of the vacuum cleaner as waste for disposal.
7. When you have finished vacuuming, turn off the vacuum cleaner and remove the PVC brush from the Antistatic hose.
8. Connect the Antistatic hose back to the connector for the Antistatic hose in the PHS
9. Mount the back service panels and screw them back in place with screws.
10. Reconnect the power supply to the PHS.
23
Image 54. Cleaning the Powder Feeding Screw with a vacuum cleaner.
, .
1 2
For these activities you will need:
G (from the box with additional accessories)
Image 55. Location of the screws holding the back service panels.
12 (image 48).
23 and both chambers inside
23
22 , 24 .
.
12
19 on the Control Panel to cut off power from
12 (image 48).
12 .
POWDER HANDLING STATION Manual | 34
