SINTERIT POWDER HANDLING STATION User Manual page 17

Image 7. Correct mounting of the Slope ramp
8. Unscrew screws the PHS device from the clamping
angles bars to the pallet
shorter sides of the device. The location of the screws
underneath the device is shown by the markers (image
8). To unscrew the screws (two for each angle, size
M10x40) use the service wrench
with 1 point - size 17.
9. Unscrew screws fixing the angle bar to the pallet
from the side of the Slope ramp, see picture opposite.
Remove it to allow the device to slide freely off the
pallet.
B
C . The angles are on both
; select the side
F
A
to the guide rail on a pallet
Image 8. Location of the angles that secure
the PHS to the pallet.
Image 9. Location of the screws securing
the angle bar to the pallet.
B
(detailed view).
C
C
POWDER HANDLING STATION Manual | 16
