SINTERIT POWDER HANDLING STATION User Manual page 26

Cleaning the printer.
Do you want to use Vacuum Cleaner or
clean the printer using manual procedure?
SINTERIT ATEX VACUUM CLEANER
Image 24. When cleaning the printer, we recommend selecting
the Sinterit ATEX Vacuum Cleaner path on the printer screen.
12. Starting with the external layers of the cake, crush it
and push the powder through the grid. Watch out for
prints inside the cake body (image 26).
13. In the end, check the amount of powder in the Powder
Chamber. You can lift the grid and, with a Powder Wiper,
clean the walls of the chamber from the powder deposited
(image 27).
Do not remove the Powder Feeding Screw guard
inside the chamber!
14. The overflow of powder (or when the powder is
solidified and does not sieve) and collected on the
Powder Feeding Screw guard
into the chamber with the Trowel (image 28). Only
the powder below the guard will be transported and
sucked in.
15. Remember to put the grid back on the Powder
Chamber 1 .
16. The extracted prints should be cleaned above the
Fine Dust Chamber grid
steel probes, and spatulas, and placed on the Worktop
(or on the Foldable Tray on the right - if there is no
sandblaster placed there) (image 29).
25 | POWDER HANDLING STATION Manual
BACK MANUAL
22 can be pressed
1 with brushes, stainless
Image 25. Pouring the contents of the IO Box
onto the Powder Chamber grid.
Image 26. Pushing the powder through the Powder Chamber grid.
22
Image 27. Cleaning the Powder Chamber walls
from embedded powder.
Image. 28. Use the Trowel to push the powder
through the Powder Feeding Screw guard.
2
Image 29. Thorough cleaning of prints above the Fine Dust Chamber.
