SINTERIT POWDER HANDLING STATION User Manual page 22

POWDER CYCLE IN PHS = POWDER + AIR + VACUUM
POWDER
AIR
VACUUM
1 2
11
IMPORTANT!
For proper powder circulation in the PHS device, extra air is needed, which is taken from above
the Fine Dust Chamber 2 . Therefore, when sucking in the powder, do not cover the chamber with
anything! When the chamber is blocked, the powder is sucked directly into the vacuum cleaner.
DO NOT COVER THE FINE DUST CHAMBER WHILE THE PHS DEVICE IS WORKING!
A minimum amount of powder above the Fine Dust Chamber is allowed, e.g. for final cleaning of prints
21 | POWDER HANDLING STATION Manual
