10. Set all castors correctly and unlock the brakes on the
front castors.
11. Carefully, with the help of another person, slide the
PHS device off the pallet (image 10). Watch out for the
feet when the device sliding off from the Slope ramp!
12. We recommend that you position the device directly at
your target workplace.
13. Lock the brakes on the castors of the PHS.
14. Remove the transport safety catches from the Drawers
the Drawer
9
15. Connect Suction hose
size 10 (two points) (image 11).
16. Place the Suction Handle in the Suction Handle socket on the PHS worktop
17 | POWDER HANDLING STATION Manual
.
3 to the device using the supplied Clamp [39]. Tighten the Clamp using the Service wrench,
3
Image 11. Locations of the Suction hose installation to the PHS device.
PUSH
EXIT DIRECTION
Image 10. The correct way to remove PHS
from the transport pallet.
7 , 8 , 9 . Remove the Suction hose
4 .
INSTALL AND SCREW
39
CAREFULLY INSERT IT INTO THE SOCKET
3
4
SECURE THE DESCENT
3 with Clamp 39 from
