3. Adjust the Powder Chamber grid
If the printout is small or has a lot of small elements,
use an Additional Powder Chamber grid with a smaller
mesh (it is located with a dedicated place in the door
of the Sifting module - image 21).
4. Remove the IO Box from Drawer 2
process of extracting the printout from the printer. The
complete process of extracting the printout from the
Lisa/Lisa PRO printer is described in the manual of the
aforementioned printer.
5. Check that the Suction Handle
in the socket . If it is not fully seated, the Powder
4
Feeding Screw mechanism will not work (image 12).
6. Switch on the vacuum cleaner (from „0" to „1"). The
Vacuum Suction sensor indicator
(image 23).
7. Press the ON/OFF Sifting button (main button)
turn on the Sifting Module
Screw (image 23)
23
8. On the Control panel, in the SUCTION section, the
LED above the DEPOWDERING ZONE
activated (image 23).
9. When the PHS device works with Lisa/Lisa PRO printers, we recommend choosing the SINTERIT ATEX VACUUM
CLEANER option on the printer screen. This is the fastest way to clean the printer from powder (image 24).
10. Gently pour the contents of the Print Bed from the IO Box onto the Powder Chamber grid
11. Clean the IO Box using a brush and put it back in Drawer 2
1 to the printout size.
8 and carry out the
3 is correctly seated
should light up
22
14 to
11 and the Powder Feeding
17 should be
Image 21. Dedicated space for an Additional
Powder Chamber grid with a smaller mesh.
Image 22. Clean the Sinetrit printers using the IO Box.
22
SUCTION
PHS
VACUUM
DEPOWDERING
HANDLE
ZONE
14
ON/OFF
SIFTING
TIMER
Image 23. Switch on the vacuum cleaner and the Sifting module.
8 .
TURN ON
POWER
VACUUM
FIRST
LIGHT
ON/OFF
17
1 (image 25).
