AN-3100D
Installation and Configuration Manual
Publication 1085-280
Rev. F
December 2012
AMETEK POWER Instruments Tel: (800) 881-4156
255 N. Union Street
Rochester, New York 14605
Fax: (585) 238-4945
Web: www.ametekpower.com

Advertisement

Table of Contents
loading

Related Manuals for Ametek AN-3100D

Summary of Contents for Ametek AN-3100D

  • Page 1 AN-3100D Installation and Configuration Manual Publication 1085-280 Rev. F December 2012 AMETEK POWER Instruments Tel: (800) 881-4156 255 N. Union Street Fax: (585) 238-4945 Rochester, New York 14605 Web: www.ametekpower.com...
  • Page 3 SERVICES DEPARTMENT BEFORE TAKING SUCH ACTIONS ***** STANDARD DEFAULT SETTINGS ARE INDICATED IN THIS MANUAL TO WHICH AN-3100D ANNUNCIATORS WILL BE SET SHOULD NO SPECIFIC CONFIGURATION OR SET UP DETAILS BE SUPPLIED WITH PURCHASE ORDERS AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL i.

  • Page 5: Table Of Contents

    ) ............40 EPEAT ELAY IRING FOR INDOWS USING TWO ARDS   I/O C ) ............42 NPUT ELAY IRING FOR INDOWS USING TWO ARDS   ) ............... 43 OMMON ERVICE IRING WITH NTEGRAL USHBUTTONS AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL i.
  • Page 6 NPUTS   .............................. 95 ISPLAY   ........................96 EPEAT ELAY UTPUTS   ..........................97 LARM EQUENCE   ............................98 ONTROLS   ..........................98 YSTEM ELAYS   ..........................98 UDIBLE EVICES   ..........................99 OMMUNICATIONS AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 7   ..........................121 INDOW EGENDS   ..........................121 INDOW OLORS   .......................... 122 INDOW SSEMBLY APPENDIX F ........................... 123  ..................... 123  ELEPHONE UMBER PROCEDURES FOR FACTORY REPAIR AND RETURN ............. 125  ..........................125  ARRANTY AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 9: Scope

    COPE This manual describes the installation and configuration of the AN-3100D annunciator system. This includes operation of its associated configuration software. Glossary of Terms Cell: Refers to a single module housing that can accommodate several boards. An Annunciator that is 3 rows high by 4 columns wide consists of 12 Cells.

  • Page 11: Product Overview

    For FM option (refer to option codes), the required door may be supplied by Ametek, a panel shop or the customer. The door must meet the FM standard for requiring a tool to open or remove the door to allow access to the front of the Annunciator Also, 120/230VAC &...
  • Page 12 The protective earth terminal is properly connected to protective earth. The line has been connected correctly and protection is provided against electric shock. Proper ventilation is provided by at least 6 inches (15.25 cm) above and below the unit AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 13: Construction

    ONSTRUCTION The AN-3100D is a modular design constructed from a matrix of cells up to 13 high by 13 wide. The cells can be configured for 1, 2, 3 or 4 points per cell. Each cell provides front access to the electronics and all wiring connections are made to the rear of the unit.

  • Page 14: Module Cell

    Power Supply: Integral AC/DC Universal, Integral DC/DC • FCV Supply Field Contact Voltage Supply: Integral AC/DC Universal • IRIG-B Time Synchronization Input Module used for Sequential Events Recording • Ground Fault Ground Fault Detector Module AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 15: Module Cell Configurations

    1.5” H x 3.0” W 1.0” H x 3.0” W 0.75” H x 0.75” W (76mm H x 76mm W) (38mm H x 76mm W) (25mm H x 76mm W) (19mm H x 19 mm W) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 16: Annunciator Model Code Definition

    Intermixed window size Item 11 Field Contact Voltage (FCV) Note: Field Contact Voltage internally supplied by AMETEK, with Option 1E indicates that the cell is expandable up to 2 inputs. common system-wide FCV return. Option 2E indicates that the cell is expandable up to 4 inputs.
  • Page 17 [must select option DNP]. Option limited to (230Vac), B(120Vac), C(125Vdc), (see 25 Cells) ITEM 10), is provided via External Supplies only. IRIG-B Time Sync Input (used with SER Option) (Standard BNC Input) Item 15 Options (continued) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 18: System Configuration And Set-Up

    YSTEM ONFIGURATION AND The AN-3100D Annunciator is already factory configured per the model number. Most of the configuration of the system is made using software, however some settings such as relay contact arrangement (Form A or Form B) needs to be configured by the user.

  • Page 19: Hardware Configuration

    As an alternative, the N/O and N/C settings may be selected via jumper P5 & P6 on the I/O Module. NOTE: The NO/NC setting must only be configured via one method (hardware or software). It is recommended to use the software method to avoid any confusion. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 20: Field Contact Voltage (Fcv)

    The Field Contact Voltage can be selected as Common throughout the whole system or Isolated from input to input. This is selected via jumpers J1 & J2. NOTE: The Annunciator is already factory configured per the selections in the model number. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 21: Optional Repeat Relays

    Form A, B and C modes. The options for the Relay Operation Mode and Relay Coil Status (normally energized or de-energized relays) are selected using the software configuration tool. (Reference the instruction manual section for Software Configuration. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 22: Csm Address

    NOTE: Care should be taken when removing and replacing I/O modules to insure that they are replaced into the cell from which they are removed. Failure to do so will result in out-of –sequence address. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 23: I/O Module Configuration

    I/O Module Configuration J1, 2 FCV Selection (1085-xxx modules containing FCV jumpers) Isolated/Common FCV P5, 6 NO / NC Inputs P2, 3, 4 Relay Output Jumpers J9 Address Selection (Configured at Factory) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 24: I/O Module Configuration

    SW1 ADDRESS SELECTION ISOLATED INPUTS COMMON INPUTS WITH FCV P5,P6: INPUT NORMALLY OPEN (NO)/NORMALLY CLOSED (NC) P2,P3,P4: RELAY OUTPUT SELECTION FORM A FORM B FORM C FORM C (N.O.) (N.C.) (SPDT) RELAY #1: RELAY #2: AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 25: Display Module

    2S, 2E, 4 1E, 2 (in CSM Cell) There is no setup required for these modules. (Factory configured) 4 Point and all options shown for reference Not all configurations have all of the displayed components. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 26: Common Service Modules

    Annunciator software configuration is performed through the CSM serial port, accessible from the front of unit. The CSM module can be configured via jumpers for Form A or B Relay Contacts. Relay output selection ( LK1-4) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 27: Communication Modules

    ‘ETH’ is included in the model number code. Systems may contain both Serial and Ethernet communications when options ‘SPT’ and ‘ETH’ are included in the model number. To verify which board you have, compare it to the pictures on the following pages. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 28: Serial Communication Only ( Original Version ) ( Part Numbers Starting With 1085- And 1086-)

    232/485 communications. It can be configured via software for all Modbus and DNP settings. RS-485 TERMINATOR J2 RS-232/RS-485 SELECTION J5 RS-232 RS-485 FLASH SYNC U8, U9 MASTER - J8 IN, J9 OUT SLAVE - J8 OUT, J9 IN AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 29: Ethernet Communications Only ( Original Version ) ( Part Numbers Starting With 1085- And 1086-)

    Alarms Option (SER or SERFR), it provides the time and date of the alarms and return to normal events. The Ethernet Communication Module has no configuration jumpers. When installed this module is mounted onto the Common Service module and together they are installed in slot 1 and 2. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 30: Serial/Ethernet Communication Module (New Version) ( Part Numbers Starting With 1087-)

    All configuration of serial and Ethernet connections is done via configuration software. This module is a 2 board assembly; a carrier card, and a communications card. This 2 board assembly mounts to the CSM module. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 31: Carrier Card

    To access this setting remove power from the system and remove the CSM and Communication board assembly from the annunciator. Remove the three screws that are used to mount the communications module to the carrier card. There are no user configurable settings on the communication card. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 32: Ground Fault Detector Module

    Several Integral Power Supply Modules are available depending on the system input power, size of the system and field contact voltage selection. There are no configurable jumpers on these modules. Refer to the power connection in this manual for the power supply images. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 33: Field Contact Voltage Supply Modules

    SER Option. This must be installed in Card Slot 5 of the CSM Cell. (When used, the Integral Power Supply must be moved to a different cell.) J P 1 , J P 2 AC/DC IRIG-B MODULE SETUP Jumper Position INPUT TYPE Modulated(AC) Demodulated (DC) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 35: Installation

    22.34 (568) 21.41 (544) 0.0625 inches 25.81 (656) 24.88 (632) (1.5mm) 29.28 (744) 28.34 (720) 32.75 (832) 31.81 (808) 36.22 (920) 35.28 (896) 39.69 1008) 38.75 (984) 43.16 (1096) 42.22 (1072) 46.63 (1184) 45.69 (1161) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 36 From the rear of the panel, replace the annunciator mounting clamps along the bottom then top and sides screws to “finger tight” check the front of panel alignment on panel face etc Fully tighten the mounting clamps. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 37: 19" Rack Mounting (Option Rk)

    Allow a minimum of 6 inches (150 mm) above the unit and behind the panel for proper ventilation. 1 Slide the annunciator assembly into the rack (from the front of the rack). 2 Secure using the recommended fixing screws into the rack mount rails. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 38: Nema Enclosure (Option N4, N4Pb)

    3.25 14.25 12.13 4.63 8.15 21.19 5 or 6H X 5 or 6W 32.00 30.00 8.15 21.19 4.31 21.19 12.13 4.63 5 or 6H X 7 or 8W 32.00 36.00 7.75 21.19 3.47 28.03 19.63 4.63 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 39: Surface (Wall) Mounting (Option S)

    4.59 4.59 4.59 ------- ------- 8.05 8.05 8.05 ------- ------- ------- 11.52 11.52 ------- ------- ------- 14.99 2.23 5.70 9.17 12.64 16.11 8.74 12.21 15.68 19.15 8.39 11.86 15.33 18.80 10.24 13.71 17.18 20.65 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 40 1.620 1.620 9.93 8.87 #6-32 x 3/4 FLATHEAD SCREW #6 HEX KEPS NUT Right side #6 HEX KEPS NUT Hinge side view #6 CUP #6 CUP WASHER WASHER #6 HEX KEPS NUT AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 41: Weather Tight Nema Front Cover (Option Ncb, Nct)

    Refer to the Panel mount option for the cutout dimensions for the annunciator, mount the door option, centered on the hole. Mount the annunciator thru the panel hole and secure with the mounting clamps as described in the panel mount installation instructions (option PM, PC) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 42 14.31 21.25 10.94 17.88 15.31 25.72 14.31 24.72 10.94 21.34 15.31 29.19 14.31 28.19 10.94 24.81 15.31 32.66 14.31 31.66 10.94 28.28 15.31 36.13 14.31 35.13 10.94 31.75 15.31 39.59 14.31 38.59 10.94 35.22 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 43 35.13 17.78 31.75 14.41 36.13 22.25 35.13 21.25 31.75 17.88 36.13 25.72 35.13 24.72 31.75 21.34 36.13 29.19 35.13 28.19 31.75 24.81 36.13 32.66 35.13 31.66 31.75 28.28 36.13 36.13 35.13 35.13 31.75 31.75 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 44 38.59 21.25 35.22 17.88 39.59 25.72 38.59 24.72 35.22 21.34 39.59 29.19 38.59 28.19 35.22 24.81 39.59 32.66 38.59 31.66 35.22 28.28 39.59 36.13 38.59 35.13 35.22 31.75 39.59 39.59 38.59 38.59 35.22 35.22 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 45: External Power Supply Mounting

    An external Power Supply is available for 120/230VAC Power and one is available for 125VDC Power also. These are used on larger systems per the power supply chart and are Class 2. 120/230VAC Power Supply 125VDC Power Supply AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 46: Wiring

    FCV is generated within the Annunciator, it is already distributed throughout the Annunciator. Each I/O card FCV connection is internally fused preventing any overload from the field. Removing an I/O card will disconnect the FCV at the terminal block for that card only. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 47: Isolated Field Contact Voltage

    Isolated Field Contact Voltage The I/O cards can be jumpered to remove the system wide bussing and replace with an individual FCV connection per input. This is shown on the drawings as well. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 48: Input / Relay Wiring For Full Size Windows (Using One I/O Card)

    Input #1 Per Input (Form A or B) Single Repeat Relay for Input #1 Per Input (Form C) Option 2RR Repeat Relay Two Repeat Relays for Input #1 Per Input (Form A or B) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 49: Input/Relay Wiring For Half Size Windows (Using One I/O Card)

    TB1 Terminal Blocks. REPEAT RELAY WIRING Option RR Input 1 + FCV Repeat Relay Option RR for Input #1 Single Repeat Relay Per Input (Form A or B) Repeat Relay for Input #2 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 50: Input/Relay Wiring For Half Size Windows (Using One I/O Card)

    TB1 Terminal Blocks. REPEAT RELAY WIRING Option RR Input 1 + FCV Repeat Relay Option RR for Input #1 Single Repeat Relay Per Input (Form A or B) Repeat Relay for Input #2 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 51: Input Wiring With Half Size Windows ( Using Two I/O Cards )

    Isolated FCV Field Contact Customer Field Contact 24,48,125 VDC 24,48,125 VDC +(L) +(L) Input 2 Input 1 120VAC, 60Hz 120VAC, 60Hz -(N) Customer FCV -(N) Customer FCV - FCV - FCV (using two I/O Cards) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 52: Repeat Relay Wiring For Half Size Windows (Using Two I/O Cards)

    Per Input (Form A or B) Per Input (Form A or B) Input 1 Option FRC Option FRC Repeat Relay Repeat Relay Single Repeat Relay for Input #2 for Input #1 Per Input (Form C) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 53 Input #3 Per Input (Form A or B) for Input #1 Per Input (Form A or B) Option RR Repeat Relay Single Repeat Relay Per Input (Form A or B) for Input #2 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 54: Input/Relay Wiring For Quad Size Windows (Using Two I/O Cards)

    Per Input (Form A or B) Option RR Option RR Repeat Relay Repeat Relay Single Repeat Relay Single Repeat Relay for Input #4 for Input #2 Per Input (Form A or B) Per Input (Form A or B) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 55: Common Service Cell Wiring (With Integral Pushbuttons)

    Ethernet IRIG-B NOTE: When wiring an external horn or other audible device to the CSM output relays, it is recommended that the interconnect wires be physically isolated from any other input or output wiring. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 56: Common Service Wiring (With I/O Modules)

    Per Input (Form A or B) Ethernet NOTE: When wiring an external horn or other audible device to the CSM output relays, it is recommended that the interconnect wires be physically isolated from any other input or output wiring. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 57: Onnecting Ower

    ONNECTING OWER The AN-3100D Annunciator operates from a selection of AC and DC Voltages. The Annunciator uses Power Supplies to provide the necessary 5VDC Logic and LED Power. If the Field Contact Voltage (FCV) needs to be provided from the Annunciator, separate FCV Supplies are provided.

  • Page 58: Power Requirements

    I/O Cards with no Size Repeat Relays Repeat Relays Full (1 per Cell) Half (2 per Cell) Third (3 per Cell) Quad (4 per Cell) Field Contact Voltage (FCV): 1.8 mA / point (nominal) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 59: Integral Power Supply

    Based on the size of the system, there could be several integral power supplies within the Annunciator. The location of integral power supplies within the Annunciator can be noted by the five position terminal block, TB5. Power Input Terminal Block AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 60: 125Vdc Or 120/230 Vac Integral Power Supply

    (1 per Cell) Half (2 per Cell) Third (3 per Cell) Quad (4 per Cell) Systems that exceed these quantities shall use an External Power Supply. 125VDC or 120/230VAC Integral Power Supply (5VDC output) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 61: 125Vdc Or 120/230Vac Integral Field Contact Voltage (Fcv) Supply

    AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 62: Vdc Integral Power Supply Wiring

    120/240 VAC 50/60 Hz Input Input Power Input Power Input 24 or 125VDC FCV 24 or 125VDC FCV (internally bussed to (internally bussed to TB1,TB2 - 2 & 4) TB1,TB2 - 2 & 4) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 63: 24Vdc Integral Power / Fcv Supply

    Quantity of Inputs per FCV Supply Field Contact Number of Systems that exceed these quantities can Voltage Inputs use multiple integral FCV Supplies 125 VDC 24VDC Integral Power Supply (5VDC Output) Shown with 125VDC FCV Supply AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 64: 48Vdc Integral Power Supply

    Note: In order to maintain a UL listing or CE Certification, any customer power supply used to provide 24VDC or 48VDC to the Annunciator shall be UL recognized or CE Certified, and provide basic insulation. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 65: And

    24VDC Power External 48 or 125 VDC FCV Integral Power Supply Power 24 VDC Input Power Input 48 or 125VDC FCV 48 OR 125 VDC FCV Internally bussed to Field Contact Voltage TB1, TB2-2&4 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 66: External Power Supply

    Third (3 per Cell) Quad (4 per Cell) For Field Contact Voltage, 24VDC can be derived from the External Power Supply 24VDC Output. For 125VDC, the Integral 24VDC Supply will be used. 120/230VAC 125VDC External Power AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 67: 125 Vdc External Power Supply Wiring

    TB1,TB2 - 2 & 4) Phoenix External 24 VDC Power Power Supply Quint-PS-100 Input 24, 48 OR 125 VDC FCV (internally bussed to TB1,TB2 - 2 & 4) To next Integral Customer Power Input Power Supply 125 VDC AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 68: 120/230 Vac External Power Supply Wiring

    24, 48, 125VDC Customer Power Input (internally bussed to Field Contact Voltage 120/240 VAC, 50/60HZ TB1,TB2 - 2 & 4) (FCV) 24 VDC Power Input External Meanwell Power Supply S-150 To next Integral Power Supply AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 69: Software Configuration

    If a configuration is edited, checks are made to ensure that the correct file is downloaded to the annunciator. If more than one version of the AN-3100D configuration software is used then more than one version of the configuration file can exist.

  • Page 70: Software Configuration Instructions

    Cell) to gain access to the CSM front mounted Serial Port. Connect the serial (one to one) cable provided with the Annunciator between the AN-3100D CSM Port and the PC with the Configuration Software installed. (Note: The serial port on the rear of the Annunciator is used for the optional communications;...

  • Page 71: Creating A New Configuration

    You can configure these options if desired and then save the file when done. Select Connections, Configuration, Write Configuration. When it is complete, select Connection, Disconnect. Press the TEST pushbutton to verify that everything is functioning correctly. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 72: Software Configuration Menus

    Connections menu performs the actual communication with the annunciator to download or retrieve configurations. Help Menu The Annunciator Configuration is equipped with a Help Menu to provide the user with assistance for each screen and program function. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 73: File

    Allows you to save the active configuration file. When clicked, it will ask you for a filename before proceeding. If the filename already exists, it will ask you if you want to overwrite the old version. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 74 Recent Files At the bottom of the file menu, you will also find a list of you most recent configuration files. You can simply click on one of these to open it. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 75: Options

    As the last open configuration is loaded when the application starts it means that the wizard will also automatically start at this point. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 76: View Configuration (Text)

    The application also includes a function to enable the configurable options in the annunciator. One such is Modbus communications. To enable any of these options you must contact AMETEK Power Instruments with your annunciator serial number that you will find in the Upgrade dialog. You will be given a unique key, which you must type into the box (shown above) and then click upgrade.
  • Page 77 It is recommended that you save any configuration changes before reading a configuration. If you wish to discard your changes you can open another document or close the application opting not to save. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 78 These values are stored independently of the annunciator hence care must taken be as if you have more than one annunciator they may not all have the same settings. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 79 In the case of a configuration mismatch it is recommended that you select the first option and then save this configuration to another location as a backup. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 80 To rectify this situation you should click "No" and then open the correct configuration file, or create a new configuration. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 81: Configuration Wizard

    Configuration Wizard The configuration of an AN-3100D is defined in a number of sections, which are displayed on separate pages. The pages may be selected by clicking on the labeled tabs at the top of each page. When a system is configured for the first time the ‘Next >>’...

  • Page 82: System

    The hardware configuration is defined in this page. The values must match the actual size of the AN-3100D. A mimic diagram of the annunciator is shown on the left hand side. The blank section on the bottom right of the annunciator is the Common Service Module (CSM).
  • Page 83 For either selection (INTB or NPB), external pushbuttons can be connected to the Annunciator terminal blocks with the same functionality. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 84 Flash Synch Master (Option FS) A software selection box is provided for flash synchronization between several different AN-3100D Annunciators. In systems that require flash synchronization, one Annunciator is configured as the Master (box checked) and all others are configured as the Slave (unchecked). Wiring between the Annunciators is required to share the flash signals.

  • Page 85: Input Configuration

    The inputs are numbered left to right and top to bottom. The inputs within a module are numbered in sequence followed by the next module. So, for example, the top row of inputs of modules with four inputs each are:- 1, 2, 5, 6, 9, 10, …… AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 86 The repeat relay will change state during an alarm and latch on until the reset pushbutton is pressed, which returns the relay to the normal state. In this mode, the relay coil is energized in the normal (non-alarm) state. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 87 If the Modbus option is included with your system, every input is defined for Transmit or Receive by clicking on the button. Transmit implies that the alarm status from hardwired contacts are sent serially to some other device. Receive AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 88 This is designed to be a summary of all the input configuration, but by clicking on the individual items you can change the selection from the table. The column widths may be adjusted by clicking and dragging on the vertical separators between the column titles. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 89 Intermittent Period ON and OFF values are 25s. Note: The intermittent on period may be adjusted automatically by the wizard so that it is set to at least one full intermittent on - off cycle. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 90 First Out, manual reset ISA-R Ringback, separate flash for return to normal ISA-RC Ringback, separate color for return to normal ISA-R-12 Automatic Momentary Ringback, dual flash, manual reset ISA-R-12C Ringback, dual color flash, manual reset AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 91 The following functions are included with the RLY Relay Option: Critical Reflash Grouped output driven by any alarm selected as critical. Upon a critical alarm, the relay output changes state. Every new critical alarm AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 92 To turn the function off click on the box again so as the tick is removed. The available functions are:- Enable Internal Horn (Option HN) When selected, this will activate the internal audible device upon any non-critical AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 93 This will pulse the critical audible output upon an alarm. Non-critical Audible Pulsed This will pulse the non-critical audible output upon an alarm. Ringback Audible Pulsed This will pulse the ringback audible output upon an alarm. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 94: Switch Inputs

    If the operational sequence chosen latches the alarm (A, M, etc.), any alarms that occurred while the inhibit switch was enabled as well as any current alarms will operate as soon as the switch returns to the ‘off’ position. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 95: Test Configuration

    For example; if the Acknowledge pushbutton is pressed before the Silence, it will not have any effect. (Note: If the Reset function is not required for the alarm sequence selected, it will be ignored.) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 96: Ascii

    The ASCII baud rate may be selected from :- 1200 2400 4800 9600 19200 The configuration application will always use the baud rate defined for the AN- 3100D. If the baud rate is changed it will not take effect until the current AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 97 In addition the RS-485 termination may be enabled The configuration application will always use the baud rate defined for the AN- 3100D. If the baud rate is changed it will not take effect until the current configuration session is complete. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 98: Modbus

    To allow the annunciator to be successfully connected to your network you will have to provide the correct subnet mask. If you do not know the correct subnet mask then you should contact your network administrator. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 99: Settings For Serial Port (Option Spt)

    3100D. If the baud rate is changed it will not take effect until the current configuration session is complete. Port Control The Modbus port may be selected from: RS-232 RS-485 9600 and 19200 baud only in slave mode In addition the RS-485 termination may be enabled AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 100: Common Modbus Settings

    Slave A Master unit may issue command functions and a slave unit responds to them. When the AN-3100D configuration application is being used the AN-3100D will be in slave mode independent of its Mode setting. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 101 Slave 0x0001 0x0002 0x0004 0x0008 Master 0x0004 0x0008 0x0001 0x0002 Modbus Type This is a format in which the data is transmitted. Can be set to ASCII or RTU. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 102: Dnp3.0

    If you do not know the correct subnet mask then you should contact your network administrator. Default Gateway Please contact your network administrator to find out whether you need to set a gateway to successfully connect to your network. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 103: Settings For Serial Port (Option Spt)

    In addition the RS-485 termination may be enabled The configuration application will always use the baud rate defined for the AN- 3100D. If the baud rate is changed it will not take effect until the current configuration session is complete. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 104: Common Dnp Configuration Settings

    This is the time the IED will wait for a Data Link confirmation. Valid numbers are 0 - 65535. Select/Operate arm time This is the time period after the select command is received that the operate command will be performed (range 0 - 65535) (Not currently used) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 105 Quick Access Toolbar Hot Keys AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 107: System Specifications

    Half Size Windows 4 LED’s / Input Third Size Windows 2 LED’s / Input Quad Size Windows 2 LED’s / Input Window Color White, Red, Yellow, Amber, Green, Blue Legends Laser printed on transparency film or Engraved AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 108: Repeat Relay Outputs

    Repeat Relay Output toggles on and off following operation of window Relay operation selectable in Software per point Relay Ratings: 24VDC @ 3.0 Amps 110VDC @ 0.1 Amps 120VAC @ 3.0 Amps Resistive Load AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 109: Alarm Sequence

    Synchronize other displays to same flash rate. Master system outputs a pulse at the slow flash rate. Slaves re-sync to incoming “lamp off” edge. A master system may drive up to 5 slave units. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 110: Controls

    Form A or Form B (N.O. or N.C.) Contact, Selectable by Jumper Relay Ratings: 24VDC @ 3.0 Amps 110VDC @ 0.1 Amps 120VAC @ 3.0 Amps Resistive Load Audible Devices Internal 80db @ 30cm audible device (option HN) External Audible Devices available AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 111: Communications

    (an event can be a point on alarm or a point that returns to normal) Note: Event memory is volatile – It requires power at all times. Power loss will clear the event buffer. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 112: Indicators

    (Option E 48VDC) 100-250 VDC (Option C 125VDC) 88-132 VAC, 60 Hz (Option B 120VAC) 176-264 VAC, 50 Hz (Option A 230VAC) Input Burden: Maximum 2.2 Watts/point (depends on window size and options selected) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 113: Mechanical

    Ethernet Communication Port -RJ45 connector IRIG-B Time Synchronization Input -BNC connector Environment Operating Temperature Range: -20 TO 50 C (-4 to 122 Storage Temperature Range: -20 TO 80 C (-4 to 176 Humidity: 20-95% RH AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 114: Electrical

    (UL Canada) Requires FM option (refer to option codes). The required door may be supplied by Ametek, a panel shop or the customer. The door must meet the FM standard for requiring a tool to open or remove the door to allow access to the front of the Annunciator.

  • Page 115: Servicing

    Severe problems/damage could occur to monitored plant/equipment should windows be replaced in incorrect positions causing erroneous indication of alarms Only remove one window assembly at a time to minimize the possible incorrect repositioning of alarm display windows AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 116: Esd

    This can be done by touching a good ground point before touching any electronic devices or assemblies. Preferably, discharge any static charge through a high impedance such as a wrist or heel strap. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 117: Operational Sequences

    SEQUENCE CODE ALARM DEVICE NORMAL ALERT ACKNOWLEDGE RETURN TO NORMAL RETURN TO NORMAL. ACKNOWLEDGE RESET BEFORE ACK R-12 VISUAL FAST SLOW SLOW SLOW AUDIBLE A distinctly different ringback audible can be provided in most cases AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 118 LAMP 2 AUDIBLE A distinctly different ringback audible can be provided in most cases Dual Lamp sequences use only inputs 1 and 3 on each input card. Inputs 2 and 4 should not be connected. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...
  • Page 119 RETURN TO NORMAL SEQUENCE CODE ALARM DEVICE NORMAL ALERT ACKNOWLEDGE BEFORE ACK. AND RESET AND RESET INITIAL NEXT INITIAL NEXT INITIAL NEXT INITIAL INITIAL RESET FAST SLOW INT. FAST INT. FAST FAST VISUAL AUDIBLE AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 120: Legend

    RETURN TO NORMAL AND ACK. RETURN TO NORMAL. INITIAL NEXT INITIAL RESET INITIAL NEXT RESET SLOW SLOW VISUAL FAST AUDIBLE For intermixed sequences specify IMO order code LEGEND LAMP OFF LAMP LAMP ON HORN OFF HORN ON FLASHING AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 121: Modbus Data Formats

    The Modbus functions are enabled by a software switch and require a key to enable them, which is supplied by AMETEK. This may be done prior to delivery or retrofitted to installed systems. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 122: (Only Available In Communication Modules With Part Numbers Starting With 1085- And 1086-)

    (Tran) to a remote device using Ack Tran and Rst Tran as shown. The Annunciator can also receive (Rec) the pushbutton controls from the remote device using Ack Rec and Rst Rec as shown. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 123: An3135 Mode

    (Tran) to a remote device using Ack Tran and Rst Tran as shown. The Annunciator can also receive (Rec) the pushbutton controls from the remote device using Ack Rec and Rst Rec as shown. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 124: Event Data

    Milliseconds (0-999) two bytes 41059 AN-3100D Point Number (1-198) 41060 IRIG-B Sync – high byte / Point Status (1 = A, 0 = N) low byte * Supports Master or Slave Mode, Transmit only AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 125: Modbus Addresses

    Baud rate 2400/4800/ 9600 9600/19200 Parity Odd/Even/none None Parity type Transmit controls Yes/No Send alarm control (ACK, RST) data Data direction Input/output Output 1 bit per point to designate Tx/Rx data Modbus format ASCII/RTU AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 127: Dnp Data Formats

    Maximum Application Layer Re-tries: Configurable from 0 to 255 None Requires Data Link Layer Confirmation: Configurable as: Never, Only for multi-frame messages, or Always Requires Application Layer Confirmation: When sending multi-fragment responses (Slave devices only) Sometimes AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 128: Implementation Table

    No Counters Reported fault Variation: MPLEMENTATION ABLE OBJECT REQUEST RESPONSE Object Variation Description Function Codes Function Codes Qualifier Codes Numbe Number (decimal) (decimal) (hex) Binary Input 1 (read) 129 (response) 00, 01 (start- stop) AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 129: Pushbutton Controls

    The Pushbutton Control Status can be checked by issuing a Binary Output Status, Object 10, variation 2. Binary Output Status (Object 10, Variation 2) DNP Object Index # Description Object Variation Number Number Reset Pushbutton Acknowledge Pushbutton AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 130: An-3100D Data Map

    Binary Input Change with Time (SER Option) The time stamped alarms are presented as Binary Input Changes with Time when the SER Option is provided. DNP Object Description Object Variation Number Number Digital Contact Alarm w/time of event AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 132: Ascii Output Format

    A – alarm N – normal hh:mm:ss.sss time to milliseconds sync state I – Irig on - no sync mm/dd/yyyy date (dd/mm/yyyy format may also be selected via the configuration software) <cr><lf> carriage return, line feed. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 133: Window Assembly Details

    In these cases, color Laser Printer should be used. Note: All legends and pre-printed colors will be provided with the Annunciator if the details are provided before the unit ships. AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 134: Window Assembly

    Window Assembly AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 135: Telephone / Fax Number List

    FAR EAST OFFICE AMETEK Power Instruments 271 Bukit Timah Road, #03-09 Balmoral Plaza, Singapore 259708 Tel: 65-732-8675 Fax: 65-732-8676 UK OFFICE AMETEK Power Instruments Unit 20, Ridgeway Donibristle Industrial Estate Dunfermline, UK Tel: 1383-825630 Fax: 1383-825715 AN-3100D ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL...

  • Page 137: Procedures For Factory Repair And Return

    Repair Sales Engineer at (800) 374-4835. ARRANTY AMETEK warrants equipment of its own manufacture to be free from defects in material and workmanship, under normal conditions of use and service. AMETEK will replace any component found to be defective, upon its return, transportation charges prepaid, within one year of its original purchase.

Table of Contents
