5. If you see the confirmation dialog box about overwriting previous values,
click Yes to continue.
6. Now click X,Y AutoFind.
Figure 53: Click 'X,Y AutoFind' to teach the horizontal position.
7. If you see another confirmation dialog box about overwriting previous
values, click Yes to continue.
8. Near the bottom-middle section of the Gantry window, click Save.
9. Now click the Trays tab, set the Dimensions for Tray 1 (number of devices
per column and row), and then click the Diagonal Corner button.
Figure 54: Setting the dimensions for your specific tray/device.
