Running a Job on PSV5000 ■ List of Steps to Start a Job
Installing the Tape-In Module Option
PSV5000 can be configured with an optional Tape-In Module (Tape Feeder)
for input media. The Tape Feeder installs on the left of the machine. A safety
plate covers the opening in the safety door when a feeder is not installed.
Reject Bin
Tape-In
(Tape Feeder)
Tape
Output
Figure 6:
shown; Bottom—3 LumenX programmers shown.
To install a Tape Feeder for input:
1. At the monitor, stop any job that is running.
- 18 -
Possible layouts with tape input; Top—5 FC programmers
Output Tray or
Reject Tray
Tray Feeder
Data I/O ■ 096-0466-001E
