Running a Job on PSV5000

Requirements

Requirements prior to running a job on PSV5000:
• A task or job for your target device must already exist. This is gen-
• You need to know the device and Socket Adapter for the target job, as
• Make sure all assemblies needed for the target job, such as the Single
Operators, please read Safety Systems on page 7 through page 12 (if you
have not already). You should generally be familiar with the
PSV5000 System.

List of Steps to Start a Job

Operator functions are in chronological order as follows:
1. Checking the System on page 14
2. Installing Input/Output Media on page 14
3. Socket Adapters and Actuator Plates on page 31
4. Installing the Correct Probes on page 38
5. Turning PSV5000 System Power ON on page 51
6. Selecting a Job and Starting CH700 on page 51
7. (Optional) Preselecting Programmers on page 56
8. Setting Media and Options—the Setup Window on page 57
see the PSV5000 Owner's Manual or your administrator.
9. (Optional) If an Automatic Tray Feeder is installed, see page 45.
10. (Optional) If Tape Output is installed, see page 23.
11. (Optional) If Laser Marking is employed, see page 44.
12. Starting Programming on page 61.
After Starting a Job...
•
•
•
•
•
PSV5000 Operator's Manual
erally an administrator function. Refer to TaskLink's online Help or
Chapter 3 of the Owner's Manual.
well as what input and output media is needed.
Tray Feeder, a Marking System or the Tape Output System, are in-
stalled on the PSV5000 Machine. Refer to Chapter 2- Set Up of the
Owner's Manual for more information.
The Package File should already have been taught. If not,
Stopping the System on page 64.
Light Tower Interpretation on page 68.
(Optional) Changing Programmer Status on page 70.
Turning PSV5000 System Power OFF on page 74.
(Optional) Operating the Single Tray Feeder on page 76.
