PSV5000 Machine Components

This Visual Index of PSV5000 locates features and subassemblies on the machine.
E-Stop
Optional:
Tape Output
Monitor and
Keyboard
Optional:
Laser Control
Light Tower
Interlocked
Safety Doors
E-Stop
Support for
Tape Feeder
Figure 1:
PSV5000 Operator's Manual
■ Work Surface Components ≡ Programmer Overview
Features of PSV5000; front (top) and back (bottom)
Gantry
Work surface
ESD ground
connection
Support for Option-
al Tray Feeder.
Accessory
Drawer
Power Panel
- 1 -
