3.2

Detailed description

Introduction
This section gives an overview of the SEMIPHOR TRANSPHOR UNIT series.
Illustration of LARGE SEMIPHOR
TRANSPHOR UNIT and SEMIPHOR
TRANSPHOR UNIT
The illustration below shows and gives a brief description of the LARGE SEMIPHOR
TRANSPHOR UNIT and SEMIPHOR TRANSPHOR UNIT.
1
Part
1
2
3
4
LARGE SEMIPHOR TRANSPHOR UNIT and SEMIPHOR TRANSPHOR UNIT require a power
supply with a minimum rating of 0 to 500 mA, 0 to 30 V. They have safety circuits built
into the instruments that limit the voltage to 30 V and the current to 0.5 A.
SEMIPHOR TRANSPHOR UNIT series Operating Instructions 29281777 AA
4
Function
Voltage leads
Top electrode
Lower electrode
Circuit breaker reset
3 System description
3.2 Detailed description
2
3
