3 System description
3.2 Detailed description
Illustration of PWR LARGE
SEMIPHOR TRANSPHOR UNIT and
PWR SEMIPHOR TRANSPHOR
UNIT
The illustration below shows the parts and gives a brief description of the PWR LARGE
SEMIPHOR TRANSPHOR UNIT and PWR SEMIPHOR TRANSPHOR UNIT.
Part
1
2
3
4
5
PWR LARGE SEMIPHOR TRANSPHOR UNIT and PWR SEMIPHOR TRANSPHOR UNIT have
a built-in power supply for transferring gels. This eliminates the need for an external
power supply. These instruments can deliver up to 30 V and 0.5 A. The instruments also
monitor the transfer stack resistance, and can stop a transfer if large changes indicate
that the buffer system is depleting.
32
1
5
2
3
4
Function
Power cord
Top electrode
Keypad
Lower electrode
Power transformer
