S&P CADB-HE BASIC Series Manual page 31

Nº Type of register
Reg.
44 Holding Register
46 Holding Register
47 Holding Register
Clogged fi lter alarm
5 Discret input
4 Coil
48 Holding Register
ODA sensor alarm
8 Discret input
SUP sensor alarm
9 Discret input
ETA sensor alarm
10 Discret input
EHA sensor alarm
11 Discret input
Description Range
Not used
Tiempo de espera 1 - 40
post Open Bypass
Fan speed 0,1 - 2
deceleration ramp
Alarm status 0
1
Type of supervision 0
1
Time to fi lter 500 - 5000
change alarm
Alarm status 0
1
Alarm status 0
1
Alarm status 0
1
Alarm status 0
1
Data Default
value
Minutes 2
V/min 0,5
Alarm not 0
active
Alarm active
Supervision 1
by time
Supervision
by pressure
switch
Hours 2500
Alarm not 0
active
Alarm active
Alarm not 0
active
Alarm active
Alarm not 0
active
Alarm active
Alarm not 0
active
Alarm active
R/W Comments
R/W
R/W
R
R/W
R/W
R
R
R
R
31
