S&P CADB-HE BASIC Series Manual page 28

Nº Type of register
Reg.
MODBUS confi guration
0 Holding Register
1 Holding Register
2 Holding Register
0 Discret input
Fans confi guration
1 Coil
4 Holding Register
3 Holding Register
5 Holding Register
1 Discret input
2 Discret input
6 Input Register
5 Input Register
2 Coil
9 Holding Register
28
Description Range
Communication 1 - 247
channel
Baudrate 0
1
2
3
4
5
6
7
8
9
10
11
12
13
Parity 0
1
2
Communication 0
alarm
1
Type of motors 0
1
Pulses per supply 1 - 5
fan turn
Pulses per extract 1 - 5
fan turn
Minimum RPM 50 - 500
Supply fan alarm 0
1
Extract fan alarm 0
1
RPM supply fan 0-5000
RPM extract fan 0-5000
Fan selection 0
master/slave
1
Unbalance slave fan -30 - 30
Data Default
value
Channel / 1
Node
110 6
300
600
1200
2400
4800
9600
14400
19200
28800
38400
56000
57600
115200
Without parity 2
ODD
EVEN
No alarm 0
Alarm active
EC fans 0
AC fans with
inverter
Pulses/Turn 1
Pulses/Turn 1
RPM 300
No alarm 0
Alarm active
No alarm 0
Alarm active
RPM supply 0
fan
RPM extract 0
fan
Supply fan 0
master
Extract fan
master
% 0
R/W Comments
R/W
R/W
R/W Involves that will exist
2 stop bits
R
R/W
R/W
R/W
R/W
R
R
R
R
R/W
R/W
