- Page 1 UK INSTALLATION AND WIRING GUIDE TO BE USED IN CONJUNCTION WITH THE MAIN INSTRUCTION MANUAL...
- Page 3 ENGLISH INDEX 1. RECOMMENDATIONS ............................4 2. GENERAL ................................4 2.1. SPEED CONTROL INPUTS ........................4 2.2. PRE-DEFINED FIXED SPEED CONTROL ....................4 2.3. REMOTE SWITCHING ..........................4 2.4. FAN-FAIL DETECTION BY FAULT SENSING ..................4 2.5. ANALOG SWITCH OUTPUTS ........................4 3.
-
Page 4: Transport And Handling
1. RECOMMENDATIONS You have purchased a CAD-EPP fan designed specifically by Soler & Palau to perform the functions described in the table of contents. Before you install and start up this product, please read this instruction book carefully because it contains important information for your safety and the safety of users during installation, use and maintenance. -
Page 5: Safety Rules
4. SAFETY RULES 4.1. ON INSTALLATION • Installation and commissioning must be done by a qualified professional specialist. • Ensure that installation complies with mechanical and electrical regulations in each country. • The equipment complies with the following Directives: EMC directive: 2014/30/UE Low voltage directive: 2014/35/UE RTTE directive: 2014/53/UE RoHS directive: 2011/65/UE... -
Page 6: Mechanical Installation
5. MECHANICAL INSTALLATION The product can be mounted in two orientations, ceiling or wall. 5.1. CEILING MOUNTING 5.2. WALL MOUNTING... -
Page 7: Maintenance Access
5.3. MAINTENANCE ACCESS The products one point of access is from the main roof. This must be followed all times to allow suitable access to the motors and filters: 5.4. CONDENSATION DRAIN PIPE The drain must be connected by means of a suitable siphon, ensuring that it is free and the rubber has not impediments and obstructions. -
Page 8: Component Locations
5.5. COMPONENT LOCATIONS... - Page 9 6. CONNECTIONS The basic wiring for the CAD-EPP has already been completed, from manufacture there is a moulded 3-pin plug with replaceable fuse pre-installed to allow the installer to connect directly into a domestic socket. L – Live N – Neutral...
-
Page 10: Control Wiring
7. CONTROL WIRING 7.1. REMOTE ENABLE (VOLT-FREE CONTACT) - Page 11 7.2. 0-10V INPUT Fan speed The speed is defined by a 0-10V input, when the control signal is received it will proportionally increase or decrease the speed of the fans depending on the input control voltage.
- Page 12 S&P REB-EPP (0-10V) Fan speed The speed is defined by the CAD-EPP, when the control signal is received it will proportionally increase the speed of the fans depending on the input voltage. NOTE!!! The REB-EPP is a S&P accessory which can be purchased using the product code L0111000000083. Please...
- Page 13 7.4. S&P AIRSENS (0-10V) Fan speed The speed is defined by the AIRSENS sensor, which will proportionally increase its control voltage depending on the pollutants or humidity in the air NOTE!!! The AIRSENS is a S&P accessory which can be purchased, there are three variations relative humidity (RH), carbon dioxide (CO2) and volatile organic compounds (VOC);...
- Page 14 7.5. BOOST (VOLT-FREE CONTACT)
- Page 15 7.6. S&P AIRSENS (BOOST) NOTE!!! The AIRSENS is a S&P accessory which can be purchased, there are three variations relative humidity (RH), carbon dioxide (CO2) and volatile organic compounds (VOC); Below lists the product descriptions and codes to be ordered. Please read this instruction booklet in conjunction with the AIRSENS booklet. 5416845300 AIRSENS CO2 5416845500...
- Page 16 7.7. PURGE (VOLT-FREE CONTACT)
- Page 17 7.9. S&P AIRSENS (PURGE) NOTE!!! The AIRSENS is a S&P accessory which can be purchased, there are three variations relative humidity (RH), carbon dioxide (CO2) and volatile organic compounds (VOC); Below lists the product descriptions and codes to be ordered. Please read this instruction booklet in conjunction with the AIRSENS booklet. 5416845300 AIRSENS CO2 5416845500...
-
Page 18: Fault Relay
7.10. FAULT RELAY Fault (Maximum current load 1A) Fault relay will activate when either fan is in fault condition, below is the operation: Fan Running/Stopped – Open circuit Fault with Fan – Closed circuit... -
Page 19: Routine Maintenance
8. ROUTINE MAINTENANCE Routine maintenance must be completed on the product to prevent premature failure: • FILTERS: The control system automatically signals the need for filter replacement. • HEAT EXCHANGER: Periodic inspection and cleaning of the heat exchanger always with an air jet to remove any impurities or deposited with the help of bactericidal products approved by health authorities. - Page 20 S&P UK VENTILATION SYSTEMS LTD S&P HOUSE WENTWORTH ROAD RANSOMES EUROPARK IPSWICH SUFFOLK TEL. 01473 276890 WWW.SOLERPALAU.CO.UK REF. REV-1...
